Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 78 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Feature: Sound Proofing Size: 85 Mm
Application: Banquet Hall,conference Room Panel Width: 500 Mm--1230 Mm
Surface: Melamine,leather,fabric,plywood Position: Interior
Width: 85 Mm(3 1/4 Inch) Finish: Melamine
Product Name: Acoustic Partition Walls Colors: Accept Customized
Open Style: Sliding
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

Conference Room Operable Acoustic Partition Walls / Commercial Folding Partition Doors

Conference Room Commercial Folding Door Partitions Operable Acoustic Partition Walls


Acoustic Partition Walls Details


Our acoustic partition wall is a movable soundproof operable walls partition system which forms a removable wall. The acoustic partitions are often used to temporarily divide a big room into several small rooms. Unlike other room partition materials, our room partition wall has excellent soundproofing performance and they are hanging on an overhead track system.



The acoustic partition wall panels are customized to meet specific requirements. Each acoustic partition board thickness is 100mm and max width is 1200mm. Each operable wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.



Specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding partitions for rooms through the ceiling track.

Conference Room Operable Acoustic Partition Walls / Commercial Folding Partition Doors 0

Specifications of Acoustic Movable Partition Walls System



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Conference Room Operable Acoustic Partition Walls / Commercial Folding Partition Doors 1



Advantages of Acoustic Partition Walls



Acoustic partition walls allow you to segregate your space for maximum potential, and are the perfect flexible space-saving solution for areas that require a partition with a higher specification.



The acoustic partition walls we supply and install here can allow 2 rooms to become one large area, with a straight forward folding screen.



Where floor area is at a premium, one large meeting room can be sub-divided into 3 smaller rooms for normal use, but when a full team meeting is required, the 2 dividers can be pulled back to give room for everyone.



Easy to operate, with powered operation available if you prefer, the walls can provide impressive sound reduction between rooms, yet open quickly to open up the space.



Acoustic partition walls can be top hung or bottom rolling, to enable them to operate no matter what the structure above. With a variety of stacking options on offer, we can neatly tuck the panels away when the wall is in the open position.



A range of panel finishes allows you to be sympathetic to your surroundings, from Melamines, to Veneers, to writable wall panels.



We pride ourselves on our professional, efficient services, delivering projects on time and within budget throughout Sheffield. For further information about any of our quality products or services, don’t hesitate to get in touch with our friendly team today.

Conference Room Operable Acoustic Partition Walls / Commercial Folding Partition Doors 2
