Sound Proofing Folding Office Acoustic Partition System For Training Conference Room

Sound Proofing Folding Office Acoustic Partition System For Training Conference Room

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 office acoustic partition

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Office Acoustic Partition Color: Wood Grain
Surface: Melamine Application: Training Room Partition
Material: MDF + Aluminum Weight: 25 Kg/m²
High Light:

Folding Office Acoustic Partition System

,

Wood Grain Acoustic Partition System

,

MDF Acoustic Partition Wall

Product Description

Sound Proofing Folding Office Acoustic Partition System for Training Conference Room





Office Acoustic Partition Detail



Our acoustic screens are a series of ceiling mount office acoustic partition which not only divide the space but also soundproof. These office acoustic partitions are often used in hotel, shops, inspection hall, multi-function rooms, station, clubs, art centers, stadium, sports centers, art museum, the court, convention center, schools, conference center, golf clubs, and so on.



Office acoustic partition are critical in most facilities that need space and acoustic control. This makes it a sound investment, especially given the fact that the technical results of the movable screen walls have become a particularly effective way to add quiet spaces to areas where sound attenuation is needed.



Planning for correct office acoustic partitions may seem to be as simple as choosing the appropriate Rw/STC level for your partition. However, the structure of the surrounding buildings also plays a key role in maintaining the desired level of sound control.



This is why the choosing of the correct office acoustic partition system for acoustic control, in conjunction with complementary architectural elements, is carefully studied and planned. We have the experience you need to provide information and guidance on best decisions about acoustics.



Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Sound Proofing Folding Office Acoustic Partition System For Training Conference Room 0





Office Acoustic Partition Features

No Floor Track

The office acoustic partitions are supported from the ceiling track, so there is no floor track to get in the way, no tripping hazard, and no gap to collect debris. When an acoustic bottom seal is required, the seal is activated from within the operable panel.

Unlimited Completion and Options

Aesthetics is vital and we offer a wide range of surface and construction options for acoustic sliding folding partitions to meet any project design and functional standards. Surface treatment options include vinyl, fabric, carpet, veneer, high pressure laminates, frescoes and other custom surfaces – MDF finish can allow customers do surface treatment on site.

Durable Partition

The office acoustic partition is made of aluminum frame with excellent durability and rigidity in a wide range of challenging applications. From 1m to 15m high, 4 different thickness of aluminum frames to make sure the durable, safety and reliable operation.
