Multi Color Acoustic Partition Wall for Conference Hall Aluminium Sliding Track Roller
|Place of Origin:||China,Guangzhou|
|Model Number:||Series 65 mm wooden partition walls|
Payment & Shipping Terms:
|Minimum Order Quantity:||10 square meters|
|Price:||107 / 131 dollar per square meter|
|Packaging Details:||Carton package, MDF batten on four section sides ,foam board on both front face.|
|Delivery Time:||Shipped in 10 days after payment, based on the quantity.|
|Payment Terms:||D/A, D/P, L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||5000 square meters per month|
|Service:||OEM Service||Height:||4 M|
|Width:||500-1200 Mm||Thickness:||65 Mm|
|Surface:||Melamine,acoustic Fabric||Open Style:||Folding|
|Sliding Style:||Sliding||Metal Type:||Aluminium|
acoustic operable partitions,
movable acoustic partition walls
Decorative Panels Sliding Doors Office Wooden Partition Wall
Movable sliding partition wall make it possible to divide the office environments, ensuring privacy, elegance, versatility, with complete freedom in designing the office furniture project, using a product that makes internal partitions true furnishing and design elements. All this thanks to a modular system that lends itself to an infinite number of configurations, the result of the evolution of the mobile office walls, representing at best the technique and design.
The office partitions can be configured with a blind panel, a dividing wall. The internal structure is made of metal box, and allows the internal ducting of the plant while externally there are double panels in melamine 9 mm thick, soundproofing inner mattress to ensure excellent soundproofing. Office Design partition walls are available in different versions: single or double, transparent or satin, all laminated with internal security film and certified for the most severe regulations. Even the standard color finishes available are many, and all finishes are available on request.
Absolute flexibility is the main advantage of the mobile office walls: it is in fact possible to configure and customize them according to the customer's needs and the designer's requests, and in case they need to be readjusted as needed. The office partitions are the result of 25 years' work and experience in the "turnkey" office and contract furniture sector of our team of architects and technical designers.
Movable partition wall is a continuously hinged system offering a mid level acoustic performance. With multiple fixed rubber sweep seals, it can offer an acoustic insulation up to 53 dB Rw. For added flexibility, or when there is no suitable structure to suspend from, it can be supplied as a bottom rolling option, running along a low profile floor track.
The movable partition wall range is our individual panel partition system offering an acoustic insulation rating of up to 53 dB Rw. Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers. The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.
|Panel suspension||Top hung only|
|Track system||Single or twin point|
|Panel thickness||65 mm||85 mm||100 mm|
|Panel height||Up to 4000mm,heights greater than 3000mm refer to our technical dept.||Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.|
500 - 1200mm
1' 5/8" -- 4'
500 - 1200mm
1' 5/8" -- 4'
500 - 1200mm
1' 5/8" -- 4'
|Fire safety||Optional class I||Optional class I||Optional class I|
|Vertical profiles||Aluminum, anodized with sealing profiles, painter optional||Aluminum, anodized with sealing profiles, painter optional||Aluminum, anodized with sealing profiles, painter optional|
|Retractable seals||Aluminum, black with double rubber seals||Aluminum, black with double rubber seals||Aluminum, black with double rubber seals|
|Operation of seals||Manual, with supplied operating handle|
|Locking||Optional lock to passing doors|
|Passing doors||Single open in one panel or double open in two panel|
|Sound insulation||32-38dB Rw||36-45dB Rw||42-55dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx 30-48kg/sq M|
With flexibility of space becoming increasingly more important, the addition of movable walls and sliding folding partitions is an ideal way of utilising existing space efficiently, effectively and economically.
Whether you want to sub-divide a classroom or office, host more than one function in a room simultaneously or create a number of rooms from one large floor space, we have a solution to suit all requirements and budgets.
Over recent years we have become an established front runner in the acoustic movable wall and sliding folding partition industry. We are proud of the fact our products are manufactured here in the UK and can lay claim to an already impressive array of prestigious projects and satisfied customers whilst we continue to enhance our reputation at the forefront of our industry.
Our central location enables us to provide fully nationwide coverage, offering a complete design, survey, installation and maintenance package which allows for a smooth running project carried out with utmost professionalism by our vastly experienced, highly skilled operatives who have the expertise to devise a solution for any scheme, even the most diverse configurations or radical surface finishes.
