Shopping Hall Mall Frameless Sliding Folding Glass Partition Doors With Dupont Roller
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Certification: | SGS,CE etc. |
| Model Number: | BG85 # movable partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 90 / 120 dollalrs per square meter |
| Packaging Details: | Shopping Hall Mall Frameless Slidng Folding Glass Partition Doors With Dupont Roller : Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | 7 to 20 work days ,it depends on the quantity |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000square meters per month |
|
Detail Information |
|||
| Product Name: | Shopping Hall Mall Frameless Slidng Folding Glass Partition Doors With Dupont Roller | Material: | MDF + Aluminum |
|---|---|---|---|
| Color: | Multe Color | Width: | 500 / 1230mm |
| Height: | 2000 / 13000mm | STC Coeffcient: | 32 / 53db |
| Key Words: | Shopping Hall Mall Frameless Slidng Folding Glass Partition Doors With Dupont Roller | ||
| Highlight: | movable walls on wheels,acoustic movable walls |
||
Product Description
Shopping Hall Mall Frameless Slidng Folding Glass Partition Doors With Dupont Roller
Description:
Our movable and operable partition system accessories are custom for each client and project , and they are also made of superior material. Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test, we have passed the Eco-protection test and Fireproof test , to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system .
|
BUNGE BG-65# Series
|
||||||||
|
Base board
|
Hoisting weight (kgs/㎡)
|
STC (db)
|
Structure material
|
Top/Bottom Telescopic mechanism(mm)
|
Width(mm) Min/Max
|
Height(mm) Min/Max
|
Thickness (mm)
|
Fire Safety
|
|
Plywood MDF
|
22-35kgs/㎡
|
32db
|
Aluminium
|
22.5mm
|
500 / 1230mm
|
2000 / 4000mm
|
65mm
|
optional class o
|
|
Melamine Surface
|
||||||||
|
Fabric/Leather Surface
|
32db / 35db
|
|||||||
|
BUNGE BG-85# SERIES |
||||||||
|
Base board
|
Hoisting weight (kgs/㎡)
|
STC (db)
|
Structure material
|
Top/Bottom Telescopic mechanism(mm)
|
Width(mm) Min/Max
|
Height(mm) Min/Max
|
Thickness (mm)
|
Fire Safety
|
|
Plywood MDF
|
28-40kgs/㎡
|
38db
|
Aluminium
|
22.5mm
|
500 / 1230mm
|
2000 / 6000mm
|
85mm
|
optional class o
|
|
Melamine Surface
|
||||||||
|
Fabric/Leather Surface
|
38db / 42db
|
|||||||
|
BUNGE BG-100# SERIES |
||||||||
|
Base board
|
Hoisting weight (kgs/㎡)
|
STC (db)
|
Structure material
|
Top/Bottom Telescopic mechanism(mm)
|
Width(mm) Min/Max
|
Height(mm) Min/Max
|
Thickness (mm)
|
Fire Safety
|
|
Plywood MDF
|
35-45kgs/㎡
|
45db
|
Aluminum
|
30mm
|
500 / 1230mm
|
6000 / 15000mm
|
100mm
|
optional class o
|
|
Melamine Surface
|
||||||||
|
Fabric/Leather Surface
|
45db / 52db
|
|||||||
Details of Shopping Hall Mall Frameless Slidng Folding Glass Partition Doors With Dupont Roller
Specification :
Panel options
There are 3 panel options;Type 65, Type 85 and Type 100, .Type 85 and Type 100 have an aluminium edge trim. Type 100 has a concealed profile detail allowing the face finish to return around the edge of each panel. Track Types
There are 2 track types. One for single roller installations and one for double rollers.Each panel option may have either track type. Panel Stacking
Panels with double rollers can be stacked in a variety of positions. Panels with a single roller may be parked to one or both sides of the opening Finishes
Virtually any finish that can be applied to a conventional wall can be applied to the Monoplan System e.g. paint or wall covering.A large number of our installations are finished in veneer,melamine or laminate.The Monoplan System can also incorporate skirtings, dados,presentation rails and display boards etc. Recent installationshave included finishes such as chalk board, cork pin board,carpet and veneer with inlay.
Acoustics
The Monoplan System offers sound reduction levels from R’w 37 – 53dB. These levels are backed up by certificates awarded by a reputable independent body. They are not in-house tested. Full test results are available on request.(see Product Selector chart on page 12 for more details)
Fire Performance
Class ‘O’ or ‘1’ Spread of Flame panels are available to your requirements. BungeType 100 has 1 hour and 1/2 hour fire assessments.
