• Acoustic Sliding Folding Partition HIgh Acoustic For Hotel Hall
Acoustic Sliding Folding Partition HIgh Acoustic For Hotel Hall

Acoustic Sliding Folding Partition HIgh Acoustic For Hotel Hall

Product Details:

Place of Origin: China
Brand Name: BUNGE
Model Number: movable partition wall series85

Payment & Shipping Terms:

Minimum Order Quantity: 10 Square Meters
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 5,000 Square Meters per Month
Get Best Price Contact Now

Detail Information

Surface: Fabric, Leather Material: Aluinium
Sliding Door Type: Partition Doors Open Style: Sliding
Max Opening Width Mm: Any Panel Widths Mm: 500 - 1230 Mm
High Light:

movable walls on wheels


acoustic movable walls

Product Description


China Acoustic Movable Partition Wall with HIgh Acoustic For Hotel Hall

>>Features & Benefits
>>Panel suspension:  Movable, top hung system without the need for a floor track
>>Panel width:  Each panel 600mm to 1200mm
>>Roller on panel:  Single roller or double roller
>>Soundproof rate:  32Db, 38dB,43dB,48dB,53dB Rw
>>Panel Frames: Heavy-duty steel-gusseted aluminum inner frames reinforced with full height
>>Track: Aluminum track or steel track
>>Top & bottom seals: Top and bottom pressure retractable seals ensure effortless moved and locked.
>>Panel stacking: Numerous panel stacking options for complete flexibility
>>Panel surface: MDF, Plywood, Wall paper, Fabric, Leather, Natural wood veneer, Melamine, Wood moldings, etc.


used office room dividers, wood partition, movable wall, restaurant partitions, soundproof folding partition, moveable partition, wall partition, living room partition wall, sandwich panel price, accordion wall, economic partition walls, folding wall, foldable partition wall, folding partition wall, movable sound proof partition, removable wall partition, folding partition, removable partition, partition, partition wall, room divider, room dividing partition, office partition, folding partition wall panel, folding wall panel, folding wall systems

Technical Parameter
 for Partition Panel

Panel Width

500 - 1230mm

Panel height

2000 - 4000mm

Sound proof

32 - 38db





Vertical profile

Anodised aluminum profiles with integrated magnetic
 strip and sealing edges on the inside

Finish options

Fabric, veneer, HPL melamine, vinyl, carpet, customers own material,
Bare finish

Base options

Plywood, Gypsum, steel, MDF

Max width


Panel weight

25 - 40 kg / sq

Pass door selection


Single or double door








The operable wall panel construction and finish materials shall consist of Class A rated materials in accordance with BUNGE Standards.


Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.


Aluminium trim


The panel trims will be standard series with exposed Aluminium trims of 10mm thickness finished in 6063 - T5 Anodized Aluminium shall be used.


The tracks are made from extruded 6063 – T6 anodized aluminum. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.

BUNGE Centre/ Side /Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method.
Aluminum trim: The panel trims will be standard series with exposed Aluminum trims of 15mm thickness finished in 6063 – T6 Anodized Aluminum shall be used.
Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system. Retractable seal drop will be 23mm.
Acoustic insulation Material: Rockwool sound absorption glass fiber shall be used.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the wall.

The panels will be stacked as per the agreed method and in accordance with the architetural plan. Centre stacking arrangement will be utilized for the subject project.
