Room Partitions Hotel Paired Aluminum Sliding Doors Leather Wall Paper
Product Details:
Place of Origin: | China |
Brand Name: | BUNGE |
Model Number: | sliding door series100 |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 Square Meters |
---|---|
Price: | US $ 100 - 300 / Square Meter |
Packaging Details: | Carton package , MDF batten on four section sides , foam board on both front face |
Delivery Time: | 10 working days after received your payment |
Payment Terms: | T/T |
Supply Ability: | 5,000 Square Meters per Month |
Detail Information |
|||
Material: | Fabric, Melamine, Wall Paper, Leather | Open Style: | Movable And Operable Partition System |
---|---|---|---|
Thickness: | 3.94 Inches | Height: | 79 - 512 Inches |
Acoustic Rating DB STC: | 45 / 55 Db | Application: | Hotel , Banquet Hall .meeting Room And So On |
Highlight: | conference room dividers,banquet hall room dividers |
Product Description
Aluminum Room Partitions , Hotel Paired Sliding Doors with 55 dB Acoustic Rate
As Operable walls are always custom manufactured to fit your opening dimensions and engineered to meet your aesthetic and acoustic requirements it is urgent that you discuss your priorities with an experienced design professional & manufacturer with a proven record of success. Moderco is at your disposal in this regard.
Specifications
Technical Parameter for Partition Panel | Panel Width | 24 - 48 inches |
Panel height | 79 - 512 inches | |
Sound proof | 42 -55 db | |
Operation | Manual | |
Frame | Aluminium | |
Vertical profile | Anodised aluminium profiles with integrated magnetic strip and sealing edges on the inside | |
Finish options | Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish | |
Base options | Plywood, Gypsum, steel, MDF | |
Max width | Unlimited | |
Panel weight | 30 – 48 kg / sq | |
Pass door selection | door | Single or double door |
Seals | Top | Manual |
bottom | Manual |
Panel Surface Finish :
The panel surface will be as per the clients requirement finished either in BUNGE factory – China or by others . The basic panels will be raw MDF (the finish materials such as laminate, veneer, melamine or fabric etc .)
Operation :
Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.
Trolley :
BUNGE Centre / Side / Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method .
Track :
The tracks are made from extruded 6063 – T6 anodized aluminum . The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets . Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .
Retractable mechanism :
The top and bottom rail of each panel shall incorporate an extruded aluminum box section mechanical seal manually operated by a handle inserted in the panel stile , turning the handle through 45 degrees shall simultaneously extend or retract the top and bottom seals through an steel and spring mechanism which shall firmly hold the seals in the retracted or extended mode . Single crank type mechanisms shall activate floor and head seals.
Applications :
Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .
Stacking :
The panels will be stacked as per the agreed method and in accordance with the architetural plan. Centre stacking arrangement will be utilized for the subject project.
