Ceiling Mounted System Hanging Acoustic Room Dividers Office Partition

Ceiling Mounted System Hanging Acoustic Room Dividers Office Partition

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 85 hanging acoustic room dividers

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Hanging Acoustic Room Dividers Panel Thickness: 85 Mm
Based Board Thickness: 9 Mm MDF Usage: Office Furniture Partition
Roller Material: POM System: Ceiling Mounted
High Light:

Hanging Acoustic Room Dividers

,

Ceiling Mounted Acoustic Room Dividers

,

Office Partition Acoustic Room Dividers

Product Description

Ceiling Mounted System Hanging Acoustic Room Dividers Office Furniture Partition





Hanging Acoustic Room Dividers Detail



At a fixed time for all-member meetings every week, the hanging acoustic room dividers can be closed, and the small conference room becomes a large conference room, which can accommodate more participants. When holding company events, room dividers can also be closed to make the venue more open. The dividers setting is more flexible. If the meeting room is large enough, the large space can be divided into several small spaces, and the space utilization rate will be higher. In this way, the space area is not wasted, but it can be used effectively and flexibly, which can save the company a lot of costs. Why not do it? The hanging acoustic room divider also has decorative functions and sound insulation functions, so it can be made according to the decoration style of the office without affecting the overall coordination of the office environment. Good sound insulation can prevent employees in the space from interfering with each other and work more at ease.




Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Ceiling Mounted System Hanging Acoustic Room Dividers Office Partition 0





Hanging Acoustic Room Dividers Features



The retractable seal helps the hanging acoustic room dividers move easily.


The overhead mechanism reduces the need for floor rails.


Combined with beautiful and sturdy.


Most of hanging acoustic room dividers is affordable.


Aluminum panel edge profiles.


Provide beautiful design and texture to meet individual needs.
