Aluminum Operable Wooden Wall Partition 85 mm Natural Wood Veneer
|Place of Origin:||China|
|Model Number:||partition wall series85|
Payment & Shipping Terms:
|Minimum Order Quantity:||10 Square Meters|
|Price:||US $ 100 - 300 / Square Meter|
|Packaging Details:||Carton package , MDF batten on four section sides , foam board on both front face|
|Delivery Time:||10 working days after received your payment|
|Supply Ability:||5,000 Square Meters per Month|
|Thickness Mm:||85mm||Weight Kg/m2:||22 / 30|
|Max Panel Height:||4000mm||Sliding Door Type:||Partition Doors|
|Frame:||Aluminum||Panel Construction / Seal:||Operable|
acoustic operable partitions,
movable acoustic partition walls
Operable Walls , Office Partition Walls with Acoustic Optional
>>Features & Benefits
>>Panel suspension: Movable, top hung system without the need for a floor track
>>Panel width: Each panel 600mm to 1200mm
>>Roller on panel: Single roller or double roller
>>Soundproof rate: 32Db, 38dB,43dB,48dB,53dB Rw
>>Panel Frames: Heavy-duty steel-gusseted aluminum inner frames reinforced with full height
>>Track: Aluminum track or steel track
>>Top & bottom seals: Top and bottom pressure retractable seals ensure effortless moved and locked.
>>Panel stacking: Numerous panel stacking options for complete flexibility
>>Panel surface: MDF, Plywood, Wall paper, Fabric, Leather, Natural wood veneer, Melamine, Wood moldings, etc.
Technical Parameter for Partition Panel
500 - 1230mm
2000 - 5000mm
32 - 38db
Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside
Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish
Plywood , Gypsum , steel , MDF
22 - 35 kg / sq
Pass door selection
Single or double door
The Special Point Processing On Movable And Operable Partition System
The principle of double skin construction on movable and operable partition system is applied consistently in the seal area in order to ensure maximum sound insulation . A spindle mechanism presses extendable, spring loaded, double seals against the fl oor and the ceiling track . Any irregularities in the fl ooring are offset by spring-loaded double chamber seals . The contact force of the sealing strips does not place excessive strain on screed fl oors , but does ensure that the Variflex system is sufficiently stable to prevent the panels moving , even in the event of an attempted forced entry .
Variflex resolves the technical issue of corner seals with specially designed, corner pieces that also reinforce the stability and sound insulation properties of movable and operable partition system
The individual panels are centred via the magnetic strips to guarantee sound positive locking and sealing.
The panels will be stacked as per the agreed method and in accordance with the architetural plan . Centre stacking arrangement will be utilized for the subject project .
Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others
