Hanging Movable Partition Walls Malaysia Acoustic Sliding Partition Wall
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | EBUNGE |
| Model Number: | Series 85 mm movable partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | 70-159 USD per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Material: | Aluminium Frame And Mdf Board |
|---|---|---|---|
| Height: | Less Then 6 M | Width: | 500-1200 Mm |
| Thickness: | 85mm | Function: | Room Divide |
| Color: | Customized | Warranty: | 3-5 Years |
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Hanging movable partition wall malaysia acoustic sliding partition wall
Description:
Bunge movable partition wall is made of high quality anodized aluminum frame with environmentally composite materials.The panels move on a ceiling track with no requirement of floor guides or rails,and they have a standard thickness of 65 mm,85 mm and 100 mm,and a width up to 1230 mm.Maximum height can reach 13 meter tall.
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Movable partition composition:
Movable partition include the track, hanging wheel, sealing strip, frame, finish, sound insulation material, telescopic mechanism, sealing strip and other parts.
1. Track: the material is made of 6063-t5 anodized aluminum, which is used for hanging the partition.
2. Double roller: the roller is made of POM, the screw is made of no. 45 tempered steel, and the hanging partition can be rotated at any Angle on the horizontal plane, and can pass through the intersection point of L,T and X of the track along the pulley.
3. Roller seat: the material is A3 steel, which connects the roller with the partition.
4. Top and bottom seal aluminum: the material is anodic aluminum oxide.Sealing the gap between the partiton to ceiling and partition to gorund. It's soundproof and can fixed the partition.
5. Sealing tape: material is PVC, surface color is black.It can reduce the sound and light.It acts as a buffer when the movable partition touched the wall.
6. Base board: medium density fiberboard,also called MDF board.
7. Sound-proof cotton: PAR sound-absorbing glass fiber. Fireproof performance, thermal resistance and noise reduction coefficient are all in line with relevant standards.
8. Aluminum frame: All the frame is made of aluminum.
9. Telescopic mechanism: it is made of standard A3 steel and spring steel, operated by pressure spring, which can automatically adjust the gap between the screen and the ground.
10. Handle: made of standard A3 steel, it is used for operating up and down telescopic mechanism.
11. Finish structure: Movable partition finish can be glass, melamine, fireproof board, fabric, leather,gypsum board and other decorative materials.
12. Light steel keel:Medium density double-sided plastic board partition and polyurethane foam insulation composite board partition, instead of the traditional brick wall paint, you can see with the progress of science and technology in our country, bring people's lives great changes.
We Offer:
A full professional movable partition wall design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
