Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand

Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 85 mm acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcome
Price: $82-98 per square meter.
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Application: Meeting Room Partitions
Function: Assemble Height: Max 6 Meters
Color: Color Chart Position: Interior
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand


Acoustic partition walls details



Our soundproof acoustic partition walls utilises up to date materials.It can attain much higher levels of sound attenuation than was previously achievable with a folding partition. The soundproof acoustic partition wall is extremely easy to use and incorporates important features ,such as integral passing door and a flush appearance when closed.



It is available as a ceiling track to hang system with our without floor location pins, or as a floor mounted system supported on an ultra low profile floor track that can be installed flush with the floor covering.



The floor mounted system utilises a ceiling guide track that can accommodate an adjustment tolerance of 22.5 mm. both systems are avialble as centre or end tracking.



The soundproof acoustic partition walls system has a unique closing device, which helps the operator achieve a flush wall in one easy movement before closing the end pass door panel. This is particularly convenient when using a ceiling hung partition without floor track.



Soundproof acoustic partition wall offers unique custom made Acoustic Movable Wall Partitions which facilitates in managing.Your space to its maximum capacity. Our movable partition wall system constitutes of panels.



Suspended individually from the rail fixed to the top of the roof. The soundproof acoustic partition wall has retractable top and bottom seals which interlocks each panel to its position. If required, hinged pass doors shall be provided through the soundproof acoustic partition walls where access is required.

Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand 0


Acoustic partition walls features



Soundproof acoustic partition wall has top hung with no floor track.



Scissor-jack operating mechanism.



Available with virtually any surface finish.



Ideal for conference centres, hotels, offices & schools.



Angled, glazed, corner or junction panels for maximum flexibility.



Single or double point suspension for versatile stacking options.



Panels with hinged pass door, single or double leaf inset pass door panels for access through.

Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand 1



Technical information



Model BG65 Series BG85 Series BG100 Series BG High-Series
Suspensionsystem Aluminum hanging Steal Hanging
Basic Thickness 65 mm 85 mm 100 mm 100 mm
Total thickness 65/75/85/95mm 80/90/100/110mm 100/120/130mm 100/120/130mm
Max Height Up to 3800 mm Up to 6000 mm Up to 8000 mm Up to 15000 mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/Ceiling Sealing Strength Telescopic aluminum tube with rubber strip.
Side walls sealing strength Double seal tape.
Sound insulation level 26-30 db 28-34 db 32-40 db 42-52 db
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

Meeting Room Division Movable Wall System Soundproof Acoustic Partition Walls Thailand 2


Aluminium accessoreis system:


Soundproof acoustic partiiton wall seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.



For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.



For panel up to 225 kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.
