Modern Hotel Movable Wall Acoustic Partition Wall Aluminium Sliding Track
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm acoustic partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | 82 / 126 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Thickness: | 65 Mm | Height: | Less Than 4 M |
|---|---|---|---|
| Width: | 800-1300 Mm | Surface: | Melamine,fabric,leather |
| Open Style: | Sliding And Folding | Function: | Divide Space |
| Application: | Hotel,banquet Hall,function Room | Product Name: | Acoustic Partition Wall |
| Material: | MDF Board+Aluminium | Type: | Modern |
| High Light: | acoustic operable partitions,movable acoustic partition walls |
||
Product Description
Modern Aluminium Sliding Track Hotel Movable Wall Acoustic Partition Walls
Specification:
Acoustic Partition Systems offer a unique facility for utilising available space in the most practical manner.
They allow a large space to be converted into smaller, separate areas, which can be converted back to a large space with the minimum of effort. Handled well and serviced regularly, they will give many years of trouble free service.
Movable Wall can source, install and maintain a wide range of Operable Walls , Moveable Partitions, Sliding Door Systems and Room Dividers from the top manufacturers and extremely competitive rates.All installations include initial requirement assessment, on-site training in use and care as well as optional maintenance servicing contracts.
Feature:
Due to the movable partition walls flexibility and cost effectiveness, it allows large rooms to be conveniently sub-divided to maximize space utilization.
Operable wall material is customized built to suit the specified requirement. Movable partition system can be made from aluminium, gypsum, MDF, melamine-faced particleboard, plasterboard, plastic, PVC, softwood, stainless steel or wood veneer.
Acoustic partition wall technical details:
Rubber sealing materials plays an important role in modern sound insulation technology, especially in doors, windows, cars, etc.
Our sealing rubber materials made by high quality EPDM rubber, foam production process.
Have outstanding temperature resistance, optimum hardness and mechanical strength for long lasting sealing results, Ozone resistance, resistance to chemical corrosion properties.
Technical information:
| TYPE | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500 - 1200mm 1' 5/8" -- 4' | 500 - 1200mm 1' 5/8" -- 4' | 500 - 1200mm 1' 5/8" -- 4' |
| Frame | Aluminum | Aluminum | Aluminum |
| Surface material | 9mm | 9mm | 12mm |
| Fire safety | Optional class I | Optional class I | Optional class I |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle | ||
| Locking | Optional lock to passing doors | ||
| Passing doors | Single open in one panel or double open in two panel | ||
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Acoustic partition wall advantage:
Individual panels that can be stored away for Maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Application:
At present, movable partition walls are widely used in hotels, hotels, multi-purpose halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government offices, hospitals, factories and other occasions.
