Office Interior Design Movable Wall Divider On Wheels For Art Gallery

Product Description

Banquet Hall Classroom Movable Wall Divider On Wheels For Art Gallery

Technical Specification

Panel Configuration – The movable partition wall panels are customized to meet specific requirements. Each movable partition walls board thickness is 100mm and max width is 1200mm. Each single movable partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.

Overhead track system – specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding movable partition walls for rooms through the ceiling track.

The movable room partition walls has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.

Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.

Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the movable partition walls panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.

Acoustic Rating – Movbale partition walls with high acoustic performance should provide an average sound attenuation of 45Db to 50DB.

Weight – The weight of each movable partition walls panel should be an average of 40 kg/m2, depending on the panel size.

Panel surface – By default it’s 9mm MDF board. However, it can be adapted to any decorative design, such as wood veneer, fabric, etc.

Applications and operations – The movable partition walls consist of a series of single flat wall panels that are manually operated and allow stacking flexibility of the center or remote side.

The features of movable partition walls

Extensive worldwide sales network that has proved that our movable partition walls work well worldwide.

Technical advice or design is available, no matter where your facility is.

Integrated space management and acoustic product solutions that can be more profitable and economical to use in your building environment.

From your first query to the completion of the project, we are here to support.

Based on years of experience in architectural and design challenges, provide industry-leading technology to solve your space problems.

Unique custom applications that is flexible enough to meet the needs of any customer.

Strong industry support for other acoustic problems, not just movable partition walls, but also acoustic wall and ceiling.

For more information about our movable partition walls, please contact us for more details.
