Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 65 mm movable partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $85-102 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Movable Partition Walls Application: Banquet Hall Partitions
Orbital Load: 380 Kg/m Panel Weight: 38 Kg/㎡
Feature: Sound Proofing Width: 700 - 1200 Mm
High Light:

movable walls on wheels

,

movable partitions systems

Product Description

Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls

Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls



Movable partition walls melamine finish



The movable partition walls series is the most popular specification range of fully operational single-panel sliding partition systems. The noise reduction of up to 50dB noise is achieved with a combination of operable top and bottom seals, high performance multiple sound absorbing material in partition walls and panel assembly design which allows noise reduction between the frame and the outer layer.



The vertical channel of each movable partition walls panel contains a polymer insert that is acoustic sealed when the panels are placed as a wall. The sound insulation partition walls are available in three thicknesses, 65mm, 80mm and 100mm, depending on the acoustic rating (from 30dB to 50dB).

Application

Movable partition wall is usually used where indoor space needs to be fully utilized. Hotels, convention centers, educational institutions, offices, training areas, etc. can all benefit from the flexibility of partition wall sound insulation system.

Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls 0



Movable partition walls technical details



Height (maximum height) 2000 - 4000 mm
Width 650 - 1200 mm
Thickness 65 mm
Left and right telescoping 140 mm
Stretching up and down 22.5 mm
Push and pull force 30 N
Orbital load 380 kg/m
Sound insulation coefficient 45 DB
Panel material MDF

Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls 1



Movable partition walls operation



When the operable seal is retracted, the movable partition walls panel slide easily along a unique aluminum overhead rail system (no floor rails are required). The telescopic end panel allows the walls to be locked off to complete the acoustic seal. The rail and carrier systems make sure movable partition wall is easy to operate and change direction, allowing panel stacking in countless configurations.



For aesthetic appeal, it is possible to provide almost any decorative finish, including veneer, laminates, walls, carpets, whiteboards and decorative lacquers.



Movable partition walls features



Many panel stack options are completely flexible.


No floor track to get in the way.


Individual movable partition wall panel can be stored to maximize the use of space.


Operable top and bottom seals for easy operation.


A wide range of surface finishes are available for movable partition walls.


High performance multiple fill for maximum noise reduction.


Sound insulation aluminum frame structure, enhance the acoustic effect.


Unique track systems ensure quiet and easy operation.


Three panel thickness are available for a variety of acoustic requirements.

Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls 2
