Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 65 mm acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $85-102 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Application: Banquet Hall Partitions
Orbital Load: 380 Kg/m Panel Weight: 38kg/㎡
Feature: Sound Proofing Width: 700 - 1200 Mm
High Light:

acoustic operable partitions

,

acoustic operable wall

Product Description

Ballroom Movable Sound Proof Partition 100 mm Thickness / Operable Partition Walls

Soundproof Folding Partition for Hotel Banquet Hall Room Divider Operable Movable Partition Wall



100 mm thickness acoustic partition walls details



As the ultra high version, pattern 100 acoustic partition wall systems are made up of a series of individual partition panel with ceiling track which make it be able to slide along the track. These acoustic partition walls on wheels are widely used in hotels, shops, exhibition centers, exhibition center, colleges, clubs, art centers, stadium, sports centers, offices, testing center, bowling centers, schools, conference center, golf clubs, etc.



The nominal thickness of movable partition wall is 100 mm.


The acoustic partition walls panel frames are made of standard construction grade aluminum alloy.


Surface panels are available in 12 mm thick MDF board, particle board, gypsum board.


Different soundproof material infill and surface material decide the acoustic performance to meet different STC requirements.

Specification

Thickness: 100 mm


Width: 700 - 1200 mm


Height: 2000 - 8000 mm


Suspension: Top hang with single or double carrier


Acoustic performance: up to STC 50dB

Ballroom Movable Sound Proof Partition 100 mm Thickness / Operable Partition Walls 0



100 mm acoustic partition walls technical details



Height (maximum height) 8000mm
Width 650~~1200mm
Thickness 96mm
Left and right telescoping 140mm
Stretching up and down 60mm
Push and pull force 30N
Orbital load 380kg/m
Sound insulation coefficient 45DB
Panel material MDF

prodcut-image



Acoustic partition walls FAQ



Q1 : What is your main product?



A1 : We can supply the acoustic partition walls system(including movable walls tracks and other accessories)as well as the installation, office furniture and some acoustic panels.



Q2 : What’s your price?



A2 : The price is based on buyer's specific requirement, so please provide below information to help us quote exact price to you.



1) Shop drawing , dimensions, quantity;



Q3 : What is the standard size ?



A3 : Our acoustic partition wall is CUSTOMER MADE. We always manufacture acoustic partition walls according to buyer's dimensions.



Q4 : What is your delivery time?



A4 : For the series we stocked 10 working days with 300m2 , For the series unstocked 40 working days with 700m2.



Q5 : What is your payment terms?



A5 : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container.



Q6 : What is your warranty ? What do we do in case of problems?



A6 : 5 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10-15 days.

Ballroom Movable Sound Proof Partition 100 mm Thickness / Operable Partition Walls 2
