1200mm Width Movable Acoustic Partition Wall Top Hanging System
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm movable partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 87 /139 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Mdf Bare Finish,fabric,leather | Height: | Less Than 4 M |
|---|---|---|---|
| Width: | 500-1200 Mm | Position: | Commercial |
| Sliding Door Type: | Sliding Wall | Product Name: | Movable Partition Wall |
| Thickness: | 65 Mm | Application: | Banquet Hall,conference Room,hall |
| Style: | Modern | ||
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Top Hanging System Sliding Aluminium Track Banquet Hall Movable Wall Acoustic Partition
Specification:
Movable partition wall also call can move partition, move partition, orbit partition. Mobile partition has the characteristics of easy installation, reusable, industrial production, fire protection and environmental protection.
Mobile partition brings great convenience to people's work, such as active screen, you are in need of it can be folded in the side, make two Spaces temporary joint and appear larger, convenient small temporary department meetings, some product USES the landless rail system, have can completely reach the effect as solid wall.
Movable Partition Wall Feature:
1. Floor less suspension: There is no track on the floor, just install the track on the ceiling;
2.Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3.Compartments environmental protection: the compartment effect is good, the maximum sound insulation coefficient up to 53 db;
4.Insulation and energy saving: excellent heat insulation performance, according to different occupancy rates, divide the large rating into small spaces to reduce air conditioning power consumption;
5.High-efficiency fire prevention: The production of high-efficiency fireproof materials, and good fireproof performance.
6.Wide range of applications: Can be used in conference halls, exhibition halls, restaurants, hotels, high-cleaning factories and offices.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Surface:
Wooden (MDF, Plywood bare raw finish)(Melamine, Veneer).
Fabric (fabric with mdf board hard covers)(fabric with sponge soft covers).
Leather (leather with mdf hard covers)(leather with sponge soft covers).
Wallpaper, Vinyl, Fireproof board.
Pu leather printing photos.
Mirror surface and veneer surface.
Advantage:
1. Each partition relies on a universal suspension wheel to make a suspended movement along the rails. It can make a 90-degree right-angle turn and can flexibly space multiple independent spaces.
2. The outer frame of the partition is made of reinforced aluminum alloy, and the interior is equipped with a retractable soundproof seal mechanism.
3. Active partition screen models: 65 type, 85 type, 100 type, ultra-high type, high interval, etc., the external reference plane gypsum board, MDF, iron, color steel and other options.
4. In the division of hotel rooms can be up to sound insulation, the highest sound insulation can reach 53 decibels.
Our service:
We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.
We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
