Product Details:

Place of Origin: Guangzhou,China
Brand Name: BUNGE
Certification: ASTM E90
Model Number: 65 mm acoustic operable walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ
Price: US $80-108 per square meter.
Packaging Details: Paper carton
Delivery Time: 15-20 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 square meters per month.
Get Best Price Contact Now

Detail Information

Feature: Fireproof And Soundproof Size: Can Be Customized
Thickness: 65 Mm(2 9/16 Inch) Color: Can Be Customized
Flame: Aluminum Materials: Aluminum Frame+MDF
Application: Hotel,restaurant Rail Load: 250-1250 Kg/m
Product Name: Acoustic Operable Walls
High Light:

acoustic operable partitions

,

acoustic operable wall

Product Description

Hotel Banquet Hall Sound Proof Movable Partitions Acoustic Operable Walls



Acoustic Operable Walls Details



Panel Suspension
Top hunge system without the need for a floor track.
Panel Width
Each panel 600mm-1200mm.
Track
Aluminum OR Steel Track
Roller on panel
Single or Double Roller
Panel Frames
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top&bottm seals
Top and bottom pressure retractable seals ensure effortless moved and locked.
Module
700mm - 1200mm maximum.
Panel stacking
Numerous panel stacking options for complete flexibility.
Panel face
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.



Bunge Acoustic Operable Walls Systems-Technical Information



Series BG65 BG80 BG100
Panel suspension Top hung only
Track system Single or twin point
Panel thickness 65mm 80mm 100mm
Panel height Up to 3500mm Up to 5200mm Up to 17000mm
Max height 3500mm 5200mm 17000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire retardant as request
Retractable seals have
Adjustable panels Manual, with supplied operating handle
Pass doors Single door or double door as request
Sound insulation 32dB 40dB 50dB
Weight Approx 22-35kg/sqm Approx 25-40kg/sqm Approx30-48kg/sqm
Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board,

Fabric, Leather, Insulation board, Fireproof board,

Wall paper, Vinyl, Painting, etc. (Customized)





Acoustic Operable Walls Features



Acoustic operable walls are specified where functional space delineation is an integral element within the partition project.



Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space utilization.



Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centers, banks and restaurants.



Partition door mechanism structure



To create a better sound insulation acoustic operable walls, we put high density fiberglass inside the partition frame, Sourcing from imported world famous fiberglass brand " Owens Corning" which is the best sound insulation cotton manufacturer.
