Product Details:

Place of Origin: Guangzhou,China
Brand Name: BUNGE
Certification: ISO 9001
Model Number: Acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ
Price: US $78-125 per square meter.
Packaging Details: Paper carton,outside with wooden boxes.
Delivery Time: 10-25 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Feature: Sound Proofing
Frame: Anodized Aluminum 6063-T5 Based Board: 9/12 Mm MDF Or Plywood
Height: Maximum 17 Meters Thickness: 65, 85 Or 100 Mm
High Light:

acoustic operable partitions

,

acoustic operable wall

Product Description

Conference Room Hall Acoustic Operable Door Partition Walls with Pass Doors



Acoustic partition walls details



Acoustic partition walls are custom built movable walls for keeping efficient open spaces. Our acoustic partition walls system is top hung system without track.Let us help you find the best flexible solution for your environment and turn the room you have into the space you need. Designed especially for space where different uses and flexible layout changes are required.


The acoustic partition wall is aluminum-framed operable partition is the most versatile acoustic partition wallsconstructed today. Acoustic partition walls are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.

Ultra-high type is designed for acoustic partition walls as high as 7 m to16 m with max soundproof rate 53 dB. Load bearing of each meter is more than 2000 kilograms, pulley bearing more than 1600 KGS, used in large place, such as banquet hall, multi-function hall, exhibition center, gym and conference room. Ultra-high type acoustic room divider is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 16 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Acoustic Operable Partition Walls With Pass Doors / Anodized Aluminum 6063 - T5 Frame 0



Technical details



Product Keywords Acoustic partition walls
Thickness 65mm, customize available.
Width 500-1228mm
Heigth 2000-4000mm
Contract Range 22.5mm
Sound insulation coefficient 28-36
Surface Material Laminate panel, Melamine panel, Hard fabric,Soft fabric etc
Frame Material 6063-T6 Aluminum Alloy
Weight 28-35
Advantage Free of floor track
Pass door selection Single or double door

Acoustic Operable Partition Walls With Pass Doors / Anodized Aluminum 6063 - T5 Frame 1



Acoustic partition walls features



1.Acoustic partition wall is no track on the floor, just install the track on the ceiling;



2.Acoustic partition wall is stable and reliable after being cut off, and it is not easy to swing;



3.Acoustic partition wall has good sound insulation effect, the maximum sound insulation coefficient can reach 42 dB;



4.Acoustic partition wall has excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;



5.Acoustic partition walls panel is hanging on the aluminum track, assembled with muti direction wheels.

Acoustic Operable Partition Walls With Pass Doors / Anodized Aluminum 6063 - T5 Frame 2
