Hotel Banquet Hall Acoustic Movable Walls Floor To Ceiling Track Aluminium Wheel

Hotel Banquet Hall Acoustic Movable Walls Floor To Ceiling Track Aluminium Wheel

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm acoustic partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 92 / 126 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Service: OEM Service Height: Less Than 4 M
Width: 500-1300 Mm Surface: Mdf Melamine,fabric,leather
Open Style: Sliding Function: Soundproof
Application: Hotel,banquet Hall Thickness: 65 Mm
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

Floor to Ceiling Track Aluminium Wheel Soundproof Material Hotel Acoustic Operable Partition Wall


Specification:

Bunge movable partition walls is made of high quality anodized aluminum frame with environmentally composite materials.The panels move on a ceiling track with no requirement of floor guides or rails,and they have a standard thickness of 65 mm,80 mm and 100 mm,and a width up to 1230 mm.Maximum height can reach 13 meter tall.

Feature:

Individual panels that can be stored away for maximum space utilization.
Operable top and bottom seals for effortless operation.
Isolated aluminium frame construction for enhanced acoustics.
High performance multiple in fill's for maximum sound attenuation.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
No floor track ensuring obstruction free threshold.
Three panel sizes to accommodate a wide range of acoustic requirements .

Hotel Banquet Hall Acoustic Movable Walls Floor To Ceiling Track Aluminium Wheel 0
Acoustic partition wall operation:

When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.

Technical information:


TYPEBG65BG85BG100
Panel suspensionTop hung only
Track systemSingle or twin point
Panel thickness65 mm85 mm100 mm
Panel heightUp to 4000mm,heights greater than 3000mm refer to our technical dept.Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
Max height4000mm6000mm18000mm
Panel width

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

FrameAluminumAluminumAluminum
Surface material9mm9mm12mm
Fire safetyOptional class IOptional class IOptional class I
Vertical profilesAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optional
Retractable sealsAluminum, black with double rubber sealsAluminum, black with double rubber sealsAluminum, black with double rubber seals
Operation of sealsManual, with supplied operating handle
LockingOptional lock to passing doors
Passing doorsSingle open in one panel or double open in two panel
Sound insulation32-38dB Rw36-45dB Rw42-55dB Rw
WeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox 30-48kg/sq M


Hotel Banquet Hall Acoustic Movable Walls Floor To Ceiling Track Aluminium Wheel 1

Acoustic partition wall structure:

Panels:The Panels will be made from 12 mm MDF boards and shall be 100 mm thick and 1230 mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.
Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.

We can offer:

We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
