Sliding Doors Movable Acoustic Room Dividers For Hotel Interior Decorative
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm acoustic room dividers |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | US $80-130 per square meter |
| Packaging Details: | Wooden boxes |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 square meter per month |
|
Detail Information |
|||
| Application: | Hotel,banquet Hall | Finishing: | Melamine |
|---|---|---|---|
| Product Name: | Acoustic Room Dividers | Width: | 500-1200 Mm |
| Type: | Manufacture | Thickness: | 85 Mm(3 1/4 Inch) |
| High Light: | conference room dividers,banquet hall room dividers |
||
Product Description
Interior Decorative Sliding Doors Movable Partitions Hotel Acoustic Room Dividers
Acoustic room dividers details
1)Hotel acoustic room dividers sound insulation from R'w 32 dB to R'w 50 dB.
2)Interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
3)To ensure additional friction connection, shall be integrated with magnetic strip.
4)Folding partition wall spring load retractable sound seal at the top and bottom element.
5)Sliding aluminium Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
Acoustic room dividers technicals
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Acoustic room dividers details
Specification:
Banquet hall acoustic room divider is a kind of sliding wall that can divide a large space into a small space. It can serve as a multi-purpose room with multiple functions.Top hanging system without floor track. Also is seal and has good sound insulation.
Our factory can provide four series product let you have a choosing. Panel height is from finished floor to ceiling or beam. Panel width is from wall to wall.
Series 65
It is thickness 65 mm (2 2/4 inch) per panel. Maximize height is about 4.2 meters.
Soundproof feature is about 32 dB to 43 dB.
Series 85
It is thickness 85 mm (3 1/4 inch) per panel. Maximize height is about 6 meters.
Soundproof feature is about 38 dB to 50 dB.
Series 100
It is thickness 100 mm (3 15/16 inch) per panel. Maximize height is about 8 meters.
Soundproof feature is about 42 dB to 53 dB.
