ASTM Standard Folding Screens Room Divider / Sliding Wall Partitions
|Place of Origin:
|85 mm acoustic room dividers
Payment & Shipping Terms:
|Minimum Order Quantity:
|10 square meters
|US Dollars 80 - 120 per square meters
|Carton package, MDF batten on four section sides , foam board on both front face.
|L/C, D/A, D/P, T/T, Western Union, MoneyGram
|50000 square meters per month
|Acoustic Room Dividers
|500 Mm--1230 Mm
|85 Mm(3 1/4 Inch)
conference room dividers,
sound proof room divider
Cheap Price Sound Proofing Decorative Movable Folding Screens Room Dividers
Acoustic room dividers description
1)Thickness panel:65mm,85mm,100mm, height from 2 meters to 17 meters
2)Top supported without floor track or guide
3) Clear anodized extruded aluminum tracks and frames,customized powder coated color are available
4) Rock wool infill,with top and bottom retractable mechanism in the middle and mdf,plywood or plaster
base board on both side
5) Sound insulation coefficien :STC 32db to 53 db, ASTM standard of acoustic tested in HongKong.
6) Available in wide range of finishes.
7) Fast delivery and Rich experiences in oversea project installation guide & supervision.
The structure of acoustic room dividers
The BUNGE acoustic room dividers structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 82 mm and depending on the insulation material ensures a soundproof resistance of 32-53dB (decibels).
When the acoustic room divider is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by ±18 mm.
The carriages are installed on every second wall panel and are located at the center of the panel. Because the acoustic room dividers wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by ±18 mm.
BUNGE movable folding partition wall is made of high quality anodized aluminum frame with environmentally composite materials.the folding partition wall panels move on a ceiling track with no requirement of floor guides or rails,the panel has a standard thickness of 65mm,85mm and 100mm,and a width up to 1230 mm.Maximum height can reach 17 meters tall.
The folding temporary partition walls consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant,schools,office,religion,hospitals,shopping arcades and many other indoor applications product.
The folding partition wall has wide range of face finishes are available:melamine faced MDF or Plywood,fabric,carpet,fabric,artificial,leather,wood veneer,high pressure laminate,Formica ,acoustic panel,white board ect.panels may also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.
|Description of the whole system
|movable partition systems
|Sound Transmission Class(STC)
|Description of accessories
|Imported dupont POM material roller,bearing capacity 225-1300kg
|Clear anodized 6063-T6 aluminum double track
|Surface finish option
|MDF,plywood, melamine,HPL,fabric,PU,wood veer, mirror steel ect.
|"T"junction, "L" juntion, cross/ "X" juntion
