Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm wooden partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 104 / 137 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Service: OEM Service Metal Type: Aluminium
Height: 4 M Width: 500-1200 Mm
Thickness: 65 Mm Panel Type: Melamine
Open Style: Folding Function: Soundproof
Application: Office, Meeting Room Color: Multi Color
High Light:

acoustic operable partitions

,

acoustic operable wall

Product Description

Finished Melamine Decorative Wooden Partition Wall / Folding Sliding Doors

Decorative Panels Sliding Doors Office Wooden Partition Wall


Partition description:


We provide best and comfortable arrangement of acoustic sliding panels suspended from ceiling track to sub-divide wide open areas which is flexible for functions like weddings, conferencing, meetings simultaneously in single big hall. This modern technical facility is known as sliding Folding partition or Movable Wall. All types of partitions are acoustically treated and aesthetically very elegant for interior. We are committed to make your space comfortable and offer a comprehensive range of sliding folding partition systems to exactly fit your requirement.



The vertical channels for each panel incorporate vinyl seal(polymer) inserts that facilitate an acoustic seal when the panels are set out as a wall. We provide Panels in three categories or thickness, 65 mm, 85 mm and 100 mm, depending on acoustic rating (from 37dB–55dB).



Finished Melamine Decorative Wooden Partition Wall / Folding Sliding Doors 0

Freature:

Top hung without track at floor level.
Retractable acoustic seals at top and base operated either by quick release handle or semi-automatically with controls.
Single or two point suspension for center or remote parking options.
Variable track arrangements for corner, three or four way abutments.

Numerous panel stacking options for complete flexibility.
Extensive range of surface finishes available, easy construction and transportation.
The system offers various levels of sound reduction.
Combines elegance with robust construction.
Allow Customization.

Technical information:



TYPE BG65 BG85 BG100
Panel suspension Top hung only
Track system Single or twin point
Panel thickness 65 mm 85 mm 100 mm
Panel height Up to 4000mm,heights greater than 3000mm refer to our technical dept. Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
Max height 4000mm 6000mm 18000mm
Panel width

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

Frame Aluminum Aluminum Aluminum
Surface material 9mm 9mm 12mm
Fire safety Optional class I Optional class I Optional class I
Vertical profiles Aluminum, anodized with sealing profiles, painter optional Aluminum, anodized with sealing profiles, painter optional Aluminum, anodized with sealing profiles, painter optional
Retractable seals Aluminum, black with double rubber seals Aluminum, black with double rubber seals Aluminum, black with double rubber seals
Operation of seals Manual, with supplied operating handle
Locking Optional lock to passing doors
Passing doors Single open in one panel or double open in two panel
Sound insulation 32-38dB Rw 36-45dB Rw 42-55dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx 30-48kg/sq M



Finished Melamine Decorative Wooden Partition Wall / Folding Sliding Doors 1


Application:


Movable walls can be applied in hotels, Muti-functions halls, Meeting Room, Convention Center, Residential area, College and School, Banquet hall, Training rooms etc. We provide quality and reliable services at very cost effective prices .



The partitions shall be top-supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used. The tracks are made from extruded anodized aluminum. The track housing shall utilize grooves and interlocking steel pins for better alignment of adjacent track section, and shall be reinforced overhead by drop rod brackets.



Advantage:



No floor rails: Top hung system without the need for a floor track.
Stable and safe: Stable and reliable after the partition, easy to swing.
Sound insulation: Sound insulation effect, the maximum sound insulation up to 570B, we can offer various levels of sound reduction.
Insulation energy saving: Excellent insulation performance, according to different seating rate, the large space is divided into small space to reduce air conditioning power consumption.
Efficient fire: The use of highly efficient fire prevention materials, fire performance is good.
Retractable and flexible: Retractable top and bottom seals ensure effortless movement of panels, numerous panel stacking options for complete flexibility,only a person can complete the whole process of cutting off.
