Melamine Surface Wooden Room Dividers For Hotel / Acoustic Soundproofing Panels
|Place of Origin:||China,Guangzhou|
|Model Number:||Series 65 mm movable partition wall|
Payment & Shipping Terms:
|Minimum Order Quantity:||10 square meters|
|Price:||103 / 136 dollar per square meter|
|Packaging Details:||Carton package, MDF batten on four section sides ,foam board on both front face.|
|Delivery Time:||Shipped in 10 days after payment, based on the quantity.|
|Payment Terms:||D/A, D/P, L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||5000 square meters per month|
|Height:||4 M||Service:||OEM Service|
|Metal Type:||Aluminium||Thickness:||65 Mm|
|Open Style:||Folding||Width:||500-1200 Mm|
movable walls on wheels,
acoustic movable walls
Wood Room Divider Hotel Movable Partition Wall
Movable sound-proof partition walls are characterized by modular elements having high acoustic insulation up to an index of 53 dB certified by an accredited laboratory. They are easily stored and slide quietly along guide rails fixed only into the ceiling. Designed to harmonize with the existing architectural style they can reach any length and up to 12 m. in height with covering in a choice of materials and finish. High-level technology guarantees quality and reliability while offering the ideal solution for a rapid, physical and acoustic division of areas destined to host large events, meetings, workshops, video conferences and training sessions.
Elevati standard acustici: Fino a Rw=55 dB.
Alta resistenza al fuoco: fino a REI 90.
Classe reazione al fuoco : Fino a CL 0.
Omologata in Classe di reazione al fuoco 1 (uno).
Ottimo isolamento termico: per riscaldare solo gli spazi utilizzati.
Formaldeide basso valore : E1.
Materiali ecologici e riciclabili.
Design and technology are the essentials of a successful alliance between architecture. The transformation of a large hall into two or more sound-insulated areas which perfectly respond to the requirements of the designer and the needs of the user without style and functionality, can all be achieved by means of movable sound-insulated walls. The use of modular elements over 4.5 meters high, on a mono-track sliding system has made it possible to rationalize space with extreme creativity. In view of the wide choice of available (in this case vertically seamless elegant ecological leatherette was used), movable walls can be personalized according to the individual whim or requirement.
The multifunctional interiors have been designed with a view to greater focus on People’s well-being with the model. The architects designed the interiors in every detail to osier the best acoustic comfort of work environments. The movable walls incentive to obtain the ISO9001 certification with level, qualifying for energy prescience and material choice.
|Panel Suspension||Top hanging system without the need for a floor track.|
|Panel Width||Each panel 600mm-1200mm.|
|Track||Aluminum Or Steel Track|
|Roller on panel||Single or Double Roller|
|Panel Frames||Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.|
|Top and bottom seals||Top and bottom pressure retractable seals ensure effortless moved and locked.|
|Module||700mm - 1200mm maximum.|
|Panel stacking||Numerous panel stacking options for complete flexibility.|
|Panel Surface||MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.|
|Finishes||Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard.|
The Steel panels are manufactured of acoustical substrate pressure laminated to both sides of steel framing members. The finish material can be wrapped around the vertical edges of the panel to create a seamless appearance between adjacent panels (standard) or the vertical edge can be completely encapsulated and protected by a decorative aluminum trim (optional). For added durability, an optional steel skin can be laminated on top of the substrate material.
The panels are available with standard acoustical substrate or optional steel skins for added durability.
Standard brimless vertical astral provide a positive interlock with adjacent panels that prevent sound leaks while producing a minimal seamless appearance at the panel face.
With a standard STC rating of 42, 45, 49, 50, and 51, offers a wide selection of sound control choices.
All panel components (top seals, bottom seals, expander closure mechanisms, etc.) are accessible from the panel perimeter and do not require removal of panel faces making panels the most serviceable panel on the market today.
A large room can be divided into two or more separate areas in an extremely area.
Flexible and versatile manner, thus clients the possibility of adapting the available space as needed. Movable sound-insulated walls your guests various architecturally pleasing environments to satisfy their requirements.
By means of movable sound-insulated walls large areas can easily be divided as required. In this way, a large restaurant can host various events taking place on the same day, which means that use of the movable partition will soon generate considerable value added to the initial investment. Finish and decoration can be personalized.
