Demountable Movable Operable Partition Walls For Multi-Function Room
Product Details:
Place of Origin: | Guangdong |
Brand Name: | BANGE |
Certification: | ISO9001 |
Model Number: | 85 mm movable partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | US Dollars 80 - 120 per square meters |
Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
Delivery Time: | 15-20 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 50000 square meters per month |
Detail Information |
|||
Open Style: | Sliding | Product Name: | Movable Partition Walls |
---|---|---|---|
Feature: | Sound Proofing | Size: | 100 Mm |
Color: | Accept Customized | Application: | Office,hotel,conference Room |
Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
High Light: | movable walls on wheels,acoustic movable walls |
Product Description
Multi-Function Room Sound Proofing Demountable Operable Movable Partitions Walls
Specification for BUNGE movable partiiton walls:
BUNGE movable partition wall is made of high quality anodized aluminum frame with environmentally composite materials.the panels move on a ceiling track with no requirement of floor guides or rails.,the panel has a standard thickness of 65mm ,80mm and 100mm,and a width up to 1219mm.Maximum height can reach 17meter tall.
The movable partition walls consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant,schools,office,religion,hospitals,shopping arcades and many other indoor applications product.
There are wide of range face finishes are available :melamine faced MDF or
Plywood,,fabric,carpet,fabric,artificial,leather,wood veneer,high pressure laminate,Formica ,acoustic panel,white board ect.,panels may also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.
BUNGE works with Architects,designer,developers,contractores and owners in design product selection,decorative finishes,project management and after-sales warranty services as her one-stop solution business service.
Movable partition walls details
1)Thickness panel:65mm,80mm,100mm, height from 2meter to 17meter
2)Top supported without floor track or guide
3) Clear anodized extruded aluminum tracks and frames,customized powder coated color are available
4) Rock wool infill,with top and bottom retractable mechanism in the middle and mdf,plywood or plaster base board on both side
5) Sound insulation coefficien :STC 32db to 53 db, ASTM standard of acoustic tested in HongKong.
6) Available in wide range of finishes.
7) Fast delivery and Rich experiences in oversea project installation guide & supervision.
Panel Suspension
|
Top hunge system without the need for a floor track.
|
||
Panel Width
|
Each panel 600mm-1200mm.
|
||
Track
|
Aluminum OR Steel Track
|
||
Roller on panel
|
Single or Double Roller
|
||
Panel Frames
|
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
|
||
Top&bottm seals
|
Top and bottom pressure retractable seals ensure effortless moved and locked.
|
||
Module
|
700mm - 1200mm maximum.
|
||
Panel stacking
|
Numerous panel stacking options for complete flexibility.
|
||
Panel face
|
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
|
||
Finishes
|
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.
|
Operation
When moving a wall panel there is a 20-25 mm gap between the top of the panel and the head tracks,there is a similar gap between the bottom of the panel and the door.
Once the panel is positioned,acoustic integrity is maintained along the top and the bottom of the panel by extending presure seals.The presure seals are extended and retracted by a single 180 degree turn of a removable of erating handle.
Final closure of the wall is achwared by extending a telescopic sleeve on the last panel.This action simultaneously extends the top and the bottom seals.
These profiles are fitted with magnetic membrances which ensure positive interlocking of the panels.Once the wall panels have been adjusted for height and level the rollers systems are locked with a fail-safe mechanism to ensure that the panels will align perfectly everytime the wall is set up.
