Malaysia Five Star Hotel Acoustic Movable Wall Folding Sliding Partition Walls
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | Model 85 acoustical room dividers |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ, small quantity welcome |
|---|---|
| Price: | $82-88 per square meter |
| Packaging Details: | Paper carton, outside with wooden box |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sliding Partition Walls | Based Board: | 9 Mm Mdf Or Plywood |
|---|---|---|---|
| Frame Material: | Aluminum Alloy | Track Material: | Aluminum Alloy |
| Size: | Partition Walls Customized | Application: | Five Star Hotel Partitions |
| High Light: | Folding Sliding Partition Walls,85mm Thickness Sliding Partition Walls,MDF Acoustic Movable Wall |
||
Product Description
Malaysia Five Star Hotel Acoustic Movable Wall Folding Sliding Partition Walls
Sliding Partition Walls Details
The sliding partition wall panels are customized to meet specific requirements. Each room partition board thickness is 85 mm and max width is 1200 mm. Each single sliding partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.
Specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding partition walls for rooms through the ceiling track.
The sliding partition wall panel has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.
Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.
Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the sliding partition walls panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 600mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Sliding Partition Walls Features
The retractable seal helps the sliding partition wall panel move easily.
The overhead mechanism reduces the need for floor rails.
Combined with beautiful and sturdy.
Sliding partition walls affordable to everyone.
Aluminum panel edge profiles.
Provide beautiful design and texture to meet individual needs.
