Product Details:

Place of Origin: China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 65 mm folding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: 70 to 100 usd
Packaging Details: Carton paper packing ,MDF batten cover all around corner
Delivery Time: 7-15 days
Payment Terms: Western Union, MoneyGram, T/T
Supply Ability: 5000 square meter
Get Best Price Contact Now

Detail Information

Material: Customized Color: Customized
Function: Folding Silding Service: OEM
Finish: Melamine MOQ: No MOQ
High Light:

acoustic folding partition

,

folding room partitions

Product Description

Urinal acoustic movable type-65 swing door top hanging track office folding partition wall for multi-function room



Specification



1) Folding room partition movable wall interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.

2) Folding room partition movable wall to ensure additional friction connection, shall be integrated with magnetic strip.

3) Folding room partition is easy element adjustment after installation.

4) Folding room partition movable wall track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers
.
5) Folding room partition movable wall surface panel shall be of 9 mm or 12 mm MDF with acoustic treatment to the required
Acoustic Movable Type -65 Top Hanging Track Folding Partition Walls For Multi - Function Room 0

Technical Information
Model BG-65 series BG-85 series BG-100 series BG-high series
Suspension system Aluminum hanging Aluminum hanging Aluminum hanging Steel hanging
Basic thickness 65mm 85mm 100mm 100mm
Total thickness 65/75/85/95mm 85/90/100/110mm 100/120/130mm 100/120/130mm
Max height Up to 3800mm Up to 4500mm Up to 6500mm Up to 12000mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/ceiling sealing strength Telescopic aluminum tube with rubber strip
Side walls sealing strength Double seal tape
Sound insulation level 26dB-30dB 28dB-34dB 32-40dB 32-40dB
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Panel density 22-28kg/sqm. 24-32kg/sqm. 32-50kg/sqm. /
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized



Acoustic Movable Type -65 Top Hanging Track Folding Partition Walls For Multi - Function Room 1



Sound proof folding partitions details



BUNGE sound proof folding partition walls are able to supply you with acoustic partitions that will look good and last for years to come, with endless possibilities of surface finishes, from standard laminate, real wood veneers, painted finishes, black board, or ready to onsite decorate by customer i.e. painting / wallpapering etc. Conference room partitions are top hung so have no floor tracks, and are more forgiving on uneven floors, with sound reduction available up to 52db.



Options include full height or inset pass doors, and glazing panels, easy to operate each panel,is manually positioned and secured into place with a winding handle to operate the mechanical seals top and bottom.



All of our sound proof folding partition walls are of the highest quality, very robust and easy to manoeuvre, and manufactured in the China, the conference room partitions panels can be stacked either in-line (single point suspension) or off-line at either end of the top track (two point suspension), with different track variations possible to suit your needs.



Sound proof folding partition walls allow you to segregate your space for maximum potential, and are the perfect flexible space-saving solution for areas that require a partition with a higher specification.

Acoustic Movable Type -65 Top Hanging Track Folding Partition Walls For Multi - Function Room 2

FAQ

Q: What is the price for movable wall?

A: Our movable wall system is customized and the cost is caculated by total square meter.Different

types have different prices.So we need you provide to us detailed dimensions like height by width,

finish options,parking options to get a quote.We also need your layout drawing if possible.

Q: Is the movable partition wall acoustic (soundproof)?

A: Yes, our movable wall ystem is soundproof.We have different acoustic materials infill to reach different

acoustic rating. And we are the only one factory who has passed ASTM acoustic test in HongKong and

get acoustic Test report.For type 65 series we can reach 45db,for type 80 we can reach 48db,for type

100 wecan reach 53db.

Q: What finish options you have for partition?

A: We have several options.We can supply you bare MDF,bare plywood or gypsum board for your o

wn decoration,We can also supply melamine laminate,high pressure laminate, wood veneer,fabric,

PU and soon.It dependson your requirement.

Q: Are you a manufacturer or trading company?

A: We are the biggest movable wall partition manufacturer in Foshan city.We have worked for this

business over 20 years. Our factory is located in Nanhai district,Foshan city.You are warm welcome

to visit us!

Q: How to install the partition? Will it difiult to be done?

A: It is not difucult to installe our partitions.Our partitions are top supported system without any floor t

rack inneed.So top

structure will be very important.We have very detailed drawings and videos showing how toinstall,so

your people just need to follow them step by step.

Q: Can you send engineer to install? What will the cost be?

A: Sure.We have two options regarding the intallation.The first option is that we will send one engineer

assupervisor.He will instruct your workers to do the job but won't do the installation by himself.

The second option is that there will be two installers (at least two) to install movable walls.

They will install the system by themselves. At the same time, they also need the asstance from local labour.

Q: Where is your office? Do you have officec in overseas?

A: So far we don't have office in overseas,our office is located in Nanhai Foshan city.But we have local

distributor for some countries,you can kindly consult our people about the overseas distributor information.

Q: Are your products guranteed?

A: Yes,all of our products carry a full 1 Year gurantee,coverig all parts and defects.We can also providean

extended arrantee if require and the products are expected to last a lifetime.
