Movable Door Sliding Wall Folding Partition Wall For Conference Room
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | 65 mm sliding folding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $78-95 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sliding Folding Partition Walls | Application: | Conference Room Partitions |
|---|---|---|---|
| Size: | Partition Walls Customized | Height: | 2000 - 40000 Mm |
| Frame Material: | Aluminum Alloy | System: | Hanging System, No Floor Track |
| High Light: | acoustic folding partition,folding room partitions |
||
Product Description
Thailand Movable Door Sliding Wall Folding Partition Wall For Conference Room
Sliding folding partition walls details
| Description of the whole system | |
| Item | Sliding folding partition walls |
| Partition Height | 2-17 meters |
| Sound Transmission Class(STC) | 32-53db |
| Description of partition accessories | |
| Roller | Imported dupont POM material roller,bearing capacity 225-1300kg |
| Track System | Clear anodized 6063-T6 aluminum double track |
| Surface finish option | MDF,melamine,HPL,fabric,PU,wood veer |
| Junction | "T"junction, "L" juntion, cross/ "X" juntion |
| Glass wool density inside | 64kg/m3 |
| Interior profile | Wooden, aluminum, steel |
| Application | Hotel, banquet hall, ballroom , conference room, classroom, function hall, auditorium |
Technical Information
| Model | BG-65 series | BG-85 series | BG-100 series | BG-high series |
| Suspension system | Aluminum hanging | Aluminum hanging | Aluminum hanging | Steel hanging |
| Basic thickness | 65mm | 85mm | 100mm | 100mm |
| Total thickness | 65/75/85/95mm | 85/90/100/110mm | 100/120/130mm | 100/120/130mm |
| Max height | Up to 3800mm | Up to 4500mm | Up to 6500mm | Up to 12000mm |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm |
| Floor/ceiling sealing strength | Telescopic aluminum tube with rubber strip | |||
| Side walls sealing strength | Double seal tape | |||
| Sound insulation level | 26dB-30dB | 28dB-34dB | 32-40dB | 32-40dB |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | ||
| Panel density | 22-28kg/sqm. | 24-32kg/sqm. | 32-50kg/sqm. | / |
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | |||
Sliding folding partition walls advantages
1. The sliding folding partition wall is a modern and advanced architectural decoration style, which can quickly separate the space, is easy to use, and has the functions of sound insulation, heat insulation and fire prevention.
2. The sliding folding partition wall panel is made of high-strength steel skeleton, special rubber, high-quality sound-insulating cotton and veneer. The board surface is flat and strong and resistant to collision.
3. The sliding folding partition wall panel is hoisted by straight and universal steel wheels embedded in the aluminum alloy track, with flexible and variable track orientation, suitable for a variety of different storage requirements.
4, The ground does not lay rails, only the rails are hung on the ceiling, and the decorative ceiling is flat; does not affect the overall continuity of the space, change invisible.
5. The sound insulation of the sliding folding partition wall panel and the horizontal rubber-insulated seals for free extension and reinforcement of the wall panel.
6. The telescopic performance operation mode fully reflects the people-oriented concept, and the touch is flexible, which is safer and more durable than the spring operation.
7. Single-opening and double-opening doors can be installed on the wall panel as needed to facilitate access.
8. The sliding folding partition wall surface can be matched with a variety of finishes to achieve a variety of decorative effects.
