Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 95 /131 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Finished: Mdf Melamine,plywood Certificate: ISO9001
Height: Less Than 4 M Thickness: 65 Mm
Width: 500-1200 Mm Application: Gallery,theater
Product Name: Sound Proof Partitions Color: Multi Color
Open Style: Sliding Folding Position: Commercial
High Light:

sounproof folding partition

,

movable soundproof partition

Product Description

Fabric Mobile Door Sliding Folding Soundproofing Partition Walls for Banquet Hall



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Specification:



Soundproofing partition wall is also called soundproof partition, removable partition, and track partition. The mobile partition has the characteristics of easy installation, reliability, industrial production, fire prevention and environmental protection.



Movable partitions bring great convenience to people's work. For example, the active screen, you can fold it aside when you need it, so that the two spaces are temporarily joined together to make it bigger and convenient for temporary departmental meetings. These products use a ceiling track system that is as strong as a wall.



Soundproof partition wall feature:



No floor rails: Top hung system without the need for a floor track.


Stable and safe: Stable and reliable after the partition, easy to swing.


Sound insulation: Sound insulation effect, the maximum sound insulation, we can offer various levels of sound reduction.


Insulation energy saving: Excellent insulation performance, according to different seating rate, the large space is divided into small space to reduce air conditioning power consumption.


Efficient fire: The use of highly efficient fire prevention materials, fire performance is good.


Retractable and flexible: Retractable top and bottom seals ensure effortless movement of panels, numerous panel stacking options for complete flexibility,only a person can complete the whole process of cutting off.



Fabric Surface Mobile Door Sliding Folding Soundproofing Partition Walls For Banquet Hall 0



Application:



Increasingly, flexible and efficient space utilization is becoming a must for offices, hotels, exhibition centers, studios and similar. Intelligent solutions are needed that facilitate multifunctional room and etc. You have at your disposal operable partition systems capable of harmoniously combining daylight-flooded and sound insulated room concepts.



Advantage:



1.it is very convenient to be able to expand or reduce it according to different needs.



2.Preservation and storage are appropriate and convenient.



3.The sound insulation is good, not only the sound insulation, but also the heat insulation.



4.The usual mobile partition, its design is relatively fashionable. So, be able to put it anywhere. Can also play a certain beautification role.



5.The stability of the mobile partition is strong. It is not easy to offset the position.



Fabric Surface Mobile Door Sliding Folding Soundproofing Partition Walls For Banquet Hall 1



Sliding aluminium profile:



Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.



Seals: Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 22.5 MM or 23 mm.



Our service:



We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.



We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
