Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $78-86 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Partitions Application: Hotel Partition Walls
Surface: Melamine Size: Accept Customized
Open Style: Sliding Color: Optional
High Light:

sounproof folding partition

,

movable sound proof partitions

Product Description

Removable Partitions Sliding Folding Sound Proof Movable Partition Walls for Hotel



Sound proof partitions details



Operation :

Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans.When closed, the operable wall shall provide a complete sound retardant barrier.No floor track shall be used.

Track :

The tracks are made from extruded 6063 - T6 anodized aluminum .The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets .Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .

Trolley :

BUNGE Centre / Side / Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method .

Aluminum trim :

The panel trims will be standard series with exposed Aluminum trims of 15mm thickness finished in 6063 - T6 Anodized Aluminum shall be used .

Panels :

The Panels will be made from 9mm MDF boards and shall be 65mm thick and 1230mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminum frames with interlocking corner construction .The panel faces shall be finished with selected material .
· Basic Panels shall be equal in module.
· Approx.Weight kg/ square meter : 2 kg
· Maximum height : 4000mm.

Panel Surface Finish :

The panel surface will be as per the clients requirement finished either in BUNGE factory - China or by others.The basic panels will be raw MDF (the finish materials such as laminate, veneer, melamine or fabric etc.)

Retractable mechanism :

The top and bottom rail of each panel shall incorporate an extruded aluminum box section mechanical seal manually operated by a handle inserted in the panel stile , turning the handle through 45 degrees shall simultaneously extend or retract the top and bottom seals through an steel and spring mechanism which shall firmly hold the seals in the retracted or extended mode .Single crank type mechanisms shall activate floor and head seals .

Seals :

Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23mm.

Acoustic insulation Material :

Rockwool sound absorption glass fiber shall be used.

Magnetic Strip :

Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the wall.

Stacking :

The panels will be stacked as per the agreed method and in accordance with the architetural plan.Centre stacking arrangement will be utilized for the subject project.

Removable Partitions Sliding Folding Sound Proof Movable Partition Walls For Hotel 0



About us



Welcome to BUNGE Factory. We have over 10 years experience for movable partition walls system. Our factory with area over 3000 m², have the advance partition technology of USA and Germany. Through our on-going commitment to process improvement, passion for innovation and rigorous quality control procedures, we design and manufacture products only the nice quality. Here is an ultra-high system sample over 8 meters height. Every client who visited us was amazing in it. So far, we exported to USA, Australia, South Africa, Lebanon, Canada, Saudi Arabia, Philippines and Malaysia.



The movable partition wall is a hanging system, which only have ceiling tracks, no floor tracks. Our full-service capabilities make us a nice partner for our customers’ space management needs. We’re always eager and willing to understand the specific requirements of project to produce exactly what’s needed. The biggest feature is the space flexible and soundproof management. Movable Partitions are widely used in the hotel banquet halls, exhibition halls, conference rooms, restaurants, office, schools, auditorium, stadium and so on. Dimensions, surface, parking styles are customized support.



We are the real manufacturer for sound proof partitions. We consult, design, manufacture. We also transport, install, maintain. Our full-service capabilities make us a nice partner for our customers’ space management needs. Architects, contractors and building owners choose us with absolute confidence. Our highly experienced team, and streamlined manufacturing processes ensures on-time, on-budget, damage-free product. Our reputation for consistent performance and reliable, worry-free delivery enables us to build lasting, long-term partnerships with our customers.





Technical information



Model BG65 BG85 BG100
Suspension System Hanging System, with ceiling rails
Basic Thickness 65mm 85mm 100mm
Max Height Max 3800mm Max 6000mm Max 8000mm
Width 800 -1230mm

Floor/ceiling Sealing

strength

Telescopic aluminum tube with rubber strip

Side Walls Sealing

Strength

Double seal tape
Base Board Thickness 9 mm 9 mm 12 mm
Vertical Profiles Aluminum anodised with sealing profiles
Retractable Seals Aluminum black with double rubber seals
Operation Manual System, with supplied operating handle
Pass Doors Single or Double Pass Through Door Available
Weight Approx 22-35 kg/m² Approx 25-40 kg/m² Approx30-48 kg/m²
Finish Options Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Removable Partitions Sliding Folding Sound Proof Movable Partition Walls For Hotel 1



Sound proof partitions features



The retractable seal helps the panel move easily.


The overhead mechanism reduces the need for floor rails.


Combined with beautiful and sturdy.


Sound proof partition is affordable to everyone.


Aluminum panel edge profiles.


Provide beautiful design and texture to meet individual needs.

Removable Partitions Sliding Folding Sound Proof Movable Partition Walls For Hotel 2
