Operable Wall Sliding Aluminium Track Folding Sound Proof Partitions For Ballroom
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 /131 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sound Proof Partitions | Finished: | Melamine,fabric,leather And Etc |
|---|---|---|---|
| Thickness: | 85 Mm | Height: | Less Than 6 M |
| Application: | Ballroom,conference Room,office | Width: | 800-1200 Mm |
| Service: | OEM Service | Open Style: | Sliding And Folding |
| Color: | Custom Designed Color | ||
| High Light: | sounproof folding partition,movable sound proof partitions |
||
Product Description
Operable Wall Aluminium Accessories Soundproof Wall Partition for Ballroom
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Specification:
The soundproof wall partition is the highest specification range of fully operable, individual-panel movable partitions system. Acoustic insulation noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple in fill's and a panel assembly design that allows an acoustic break between the frame and outer layer.
The vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall. Panels are produced in three thickness, 65 mm, 85 mm and 100 mm.
Soundproof partition wall feature:
Easy To move and soundproof
Thanks to the exclusive system: Polymer coated , self-lubricating, wear-resistant ball bearing trolleys.
Technical reliability
In its versions, range has undergone the most stringent endurance and mechanical resistance tests in laboratories or in own Test Center. 3-years warranty for parts and labour.
Quick to install
Tool locking of top and bottom rubber seals thanks to a manual system in each panel.
Surface
Melamine,plywood,acoustic fabric and leather
Framework (stylist)
Aluminium profiles that become totally invisible when flat by means of a hollow joint system.
Application:
The acoustic sliding folding partition system is totally top supported, no floor tracks, no wall jam on wall , manually operated panels of convenient sizes, and can be stacked in area at ends with various parking option. The system when closed, its provide proper wall with complete sound barrier, the sound reduction is up to 53 db as per site condition.
This sliding folding partition system can be applied in hotels, Muti-functions halls, Meeting Room, Convention Center, Residential area, College and School, Banquet hall, Training rooms etc.
Soundproof partition wall structure:
Soundproof partition walls offer the widest range of styles and applications. From a small meeting room to a huge arena.
Soundproof partition walls consist of individual panels which are suspended from a head track system and then locked into place to create an acoustic wall. The systems can be on a single point or double point suspension. The panels can be stacked away using many different parking variations allowing maximum use of space.
Advantage:
Divide the whole area into a number of rooms.
Provide privacy to the inmates from sight and sound.
Are fashionable in design, sizes and finishes customization.
Occupy lesser area.
Ceiling tracks, no floor track.
Sliding and folding.
Easily operate by manual in any position.
We can offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
