Hotel Rolling Mobile Partition Wall / Acoustic Movable Soundproof Partition Wall

Hotel Rolling Mobile Partition Wall / Acoustic Movable Soundproof Partition Wall

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 65 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $85-102 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Partitions Application: Hotel Partition Walls
Size: Partition Walls Customized Sound Insulation: Up To 45 Db
Advantage: No Floor Tracks Surface: Melamine, Laminate
High Light:

sounproof folding partition

,

movable sound proof partitions

Product Description

Hotel Rolling Mobile Partition Wall / Acoustic Movable Soundproof Partition Wall

Hotel Rolling Mobile Partition Wall Acoustic Movable Sound Proof Partition Walls in United States



Sound proof partitions details



The sound proof partition is smooth opening and closing of spaces in areas where the movement cycle of the wall is a daily, seasonal, spring, autumn, winter closed, opening the summer, Designed against: the heat the cold, the rain (with overhead guard), the wind, the noise. Sound proof partition is used in local with balconys, terraces, shops, bars, restaurants, swimming pools, fitness centers, hotels, sports centers, shopping malls and financial institutions. Wall composed of several individual elements in glass, which slide along a guide fixed to the ceiling are assembled one after another until the whole wall is completed, you can request the inclusion of passing doors the telescopic end element is the mechanism that provides for the total closure of the wall. A double-laminated glass and toughened with pre-chamber, and argon gas transmittance up to U = 2.0 W/m2 K with horizontal and vertical profiles with thermal break from the innovative design, are made of anodized aluminum (standard) or RAL colors on request. Element with a maximum height of 400 cm, width from 80 to 100 cm, thickness 6.9 cm. The runner is made of extruded profiles with a height of 9 cm, 9.3 cm wide, in line from 45 ° and 90 ° used for the storing areas. There is no special floor guide. The trolleys of support for element have two axes of the load of 150 Kg.



We offer a high quality range of sound proof partitions which finds its wide application in various offices, restaurants, hotels and factories. These sound proof partitions are use to divide the room into various compartments in order to offer privacy to the people. These partitions find their place in offices to divide the cabins of employees. Available in various customizations, these sound proof partitions are offered at industry leading prices.

prodcut-image



Sound proof partition walls technical details

Description of Goods Sound proof partition walls
Each panel load-bearing weight 225kgs/ 450kgs/ 650kgs
Material MDF, Fabric, sound absorption materials,aluminium
suitable height space From 2m-16m
Frame Marterial Aluminum
Thickness 65/80/100mm
Core Material Standard MDF
Frame Marterial Aluminum Aluminum
Certificate SGS ,CE
System Manual ,Semi-Auto,Full-Auto

Hotel Rolling Mobile Partition Wall / Acoustic Movable Soundproof Partition Wall 1



Sound proof partitions features



1.Top hung system without the need for a floor track.



2.Retractable top and bottom seals ensure effortless movement of panels.



3.Combines elegance with robust construction.



4.Concealed or exposed panel edge profiles.



5.Numerous panel stacking options for complete flexibility.



6.Sealed for life roller assemblies provide smooth and silent movement.​The sound proof partition system offers various levels of sound reduction.



7.Extensive range of surface finishes available.



Pattern Hoist Weight STC Frame Material Track Loading Weight Retractable Range of Top/Bottom Width (Min/Max)

Height

(Min/Max)

Thickness

(Min/Max)

kg/m2 db kg/m mm mm mm mm
LY-65 30 32 Aluminium 225 22.5 750-1200 2000-3000 65
LY-80 35 38 Aluminium 450 22.5 750-1200 3000-5000 80
LY-100 45 45 Aluminium 675 22.5 750-1200 5000-10000 100

Hotel Rolling Mobile Partition Wall / Acoustic Movable Soundproof Partition Wall 2
