Meeting Room Sound Proof Partitions / 2000mm Height Hanging Sliding Partition Walls
Product Details:
Place of Origin: | Guangzhou,China |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
Minimum Order Quantity: | 20 square meters |
---|---|
Price: | $80-130 per square meter. |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | 7-10 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month. |
Detail Information |
|||
Color: | Accept Customized | Height: | 2000/13000 Mm |
---|---|---|---|
Product Name: | Sound Proof Partitions | Feature: | Sound Proofing |
Thickness: | 85 Mm(3 1/4 Inch) | Material: | MDF+Aluminum |
High Light: | movable sound proof partitions,movable soundproof partition |
Product Description
Hanging Sliding Partition Wall,Meeting Room Movable Walls,Sound Proof Partitions
Sound proof partitions details:
With the efficient use of modern space and the way people fast rhythm of life, more and more of the interior design industry began to use movable sound proof partition.
Sound proof partitions can achieve to the comprehensive, more flexible use of the space, also can repeat folding, repeated use of the space, also have played an important role in energy conservation and environmental protection, bring great convenience to people's life space.
You know, like hotel,banquet hall, occupy more space is also has limitations, hotel,banquet hall carried by the large space is to satisfy the customer's dining function and comfortable environment, due to considering the different customer the different demand for space environment, thus make the diversification of the sound proof partitions design layout, also attract attention, in a sense, it is indeed a great innovation!
To hotel configuration sound proof partitions, feeling giving a person sudden passion and vitality, a new feeling to the person, the use effect of whole space will make you great view also moments of tall, no matter how much space can be divided into multiple independent small space at any time, repeat folding can be used, concise and easy, also fully shows the interior space of the space art, not only in the hotel,banquet hall can you see the movable partition, it can also be applied to large-scale high-end conference rooms, exhibition halls, classrooms, gymnasium and other professional venues.
Sound proof partitions operation:
When moving a wall panel there is a 22.5-25 mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.
Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.
The pressure seals are extended and retracted by a single 180°turn of a removable operating handle.
Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
Technical information:
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Sound proof partitions features:
- Robust aluminium frame construction for demanding environments.
- Hinged panels for quick and easy operation.
- Wide range of surface finishes.
- Pass door incorporated enabling access to adjoining rooms.
- Stacks one or both ends.
- Top hung and floor with vinyl seals achieving excellent insulation effect.
