Abrasion Resistance Wooden Folding Partition Walls For Conference Room 7m Height
Product Details:
Place of Origin: | China,Guangzhou |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | Series 100 mm folding partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | 92 / 135 dollar per square meter |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month |
Detail Information |
|||
Product Name: | Folding Partition Walls | Height: | 7 M |
---|---|---|---|
Thickness: | 100 Mm | Application: | Conference Room,hotel |
Finished: | Melamine,Leather ,fabric | Door Material: | Aluminium Alloy |
High Light: | acoustic folding partition,folding room partitions |
Product Description
Slidng Aluminim Accessories Conference Room Wooden Folding Partition Wall
Specification:
Movable walls partition, to achieve all-round, multi-space perspective flexible separation, can be repeated folding, space reuse, energy saving, simple and generous, fully demonstrated demonstrate the art of interior space of the space.
High quality. The use of environmentally friendly materials, formaldehyde emission in line with national standards {1.5mg / L}, The material has strong, durable (abrasion resistance), fire protection, anti-deformation, anti-flammability, anti-aging, fastness, etc.anti-aging;
High noise. Fully meet the five-star hotel noise standards, the highest sound insulation up to 55db (more than 30% stronger than ordinary indoor wall insulation).
Feature:
Top hung system without the need for a floor track.
Retractable top and bottom seals ensure effortless movement of panels.
Concealed or exposed panel edge profiles.
Numerous panel stacking options for complete flexibility.
Extensive range of surface finishes available, easy construction and transportation.
The system offers various levels of sound reduction.
Combines elegance with robust construction.
Application:
Wide range of applications. Movable walls partition screen used in the star hotel Banquet Hall, Conference Room, Exhibition Hall, Office, Multi-Function Hall and other large space need to be divided into places;
Can be customized on demand. Customized according to the different needs of customers, such as cut off the model, surface decoration and collection methods such as design, to meet the different site decoration style.
Operation:
A large amount of repairs are as a result of incorrect operation by users. Movable wall panels are deceptively heavy due to the ease of operation but are capable of serious crush injuries.
Your work place risk assessments should have taken this into account and state that only trained and authorized personnel may operate the wall. we will offer training on the safe and correct operation of your system to your staff.
Movable walls and sliding folding partitions do have a life cycle and there is a point where maintenance and repairs become either impossible or uneconomical.
Technical information:
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Usage:
(1)Constructing location: keep dry, the temperature should be higher than 10'C, the widest humidity range should confined to 40%-60% after construction 24 hours before constructing, the location should reach the standards as above.
(2)Acoustic panels: for the acoustic panels accommodated to the circumstance of constructing, please place the panels in the constructing location for 48 hours, check up the type, specification and amount of the panels before constructing.
We can offer:
A full professional design service.
Survey and installation service - using UK manufactured materials and components and a fully experienced fitting team.
Maintenance contracts - to ensure your valuable asset remains in full working order.
Over 20 years industry experience employed for every installation we complete.
