Aluminium Track Roller Melamine Surface Portable Room Divider Sliding Folding Partition Walls
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm folding partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 95 / 124 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Melamine,leather,fabric | Thickness: | 65 Mm |
|---|---|---|---|
| Height: | 4 M | Application: | Office,banquet Hall,multi Function Room |
| Width: | 500-1200 Mm | Product Name: | Folding Partition Wall |
| Position: | Commercial | Sliding Door Type: | Folding Doors |
| High Light: | soundproof folding partition,folding room partitions |
||
Product Description
Melamine Portable Room Divider Folding Office Partition Wall
Specification:
Our folding partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.
Folding Partition Wall Feature:
Full modular.
Pivot, stack or move the panels as you see fit and create a visual journey specific to each artist.
With infinite possibilities
The panels can be painted on site to complement the decor or covered with the coating of your choice.
Fluid and fast operation
A variable frequency motor adjusts the speed of deployment, allowing smooth straightening, reducing stress on the rail.
Deployment in a restricted area
As panels recover more quickly, less side clearance is required during the operation.
Increased stability
The chain drive is more stable than cable, reducing the required system maintenance.
Discreet hinges
A trolley on each panel allows the use of more discreet hinges, reducing the risk of injury.
Unique in cortex
Noise is not just a story of volume. When a calm and soothing work environment is essential to the business, movable partitions provide unparalleled acoustic comfort by controlling the main irritant:
the reverberation of the sound.
The most advanced acoustic treatment
Movable partitions offer an integrated acoustic treatment to their composition, allowing to manage well the reverberation and the propagation of the sound. This acoustic treatment system offers increased resistance to impacts and impacts.
Aesthetic freedom
Performance Plus partitions offer a continuous surface that can be enhanced with an unrivaled choice of finishes and textures, becoming an architectural element of your design and creating a high-performance workspace.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Folding partition instruction:
First, how to open a muti-directional screen. All operations should be gentle and should pay attention to safety. Facing the screen station, use both hands to grab the screen and pull the screen in the direction of the rails; turn the screen in the direction of the rails. After pushing the screen to its place, fix the screen. Tip: When pushing the screen to the intersection, you should pay attention to the direction of the rail, and then gently push the screen along the rail to the position where it should be placed.
Second, how to fix a muti-directional screen. With one hand holding the screen, the other hand puts the handle into the hexagonal steel at 1100mm on the side of the screen, grasps the handle and rotates it 180 degrees in the clockwise direction, and the telescopic seal inside the screen pops up to fix the screen. Insert the handle into the groove on the side of the screen, and pull the handle upwards to open the expansion screen inside the screen to fix the screen. After the entire group of screens are placed, check whether the screen is straight, whether it is on the same plane as the rails, and if it is not straight, retract the upper and lower expansion seals until the screen is flat.
