Ceiling Suspended Decorative Modern Movable Mound Proof Partition Wall With Rails
Product Details:
Place of Origin: | Guangdong |
Brand Name: | BANGE |
Certification: | ISO9001 |
Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | US Dollars 80 - 120 per square meters |
Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
Delivery Time: | 15-20 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 50000 square meters per month |
Detail Information |
|||
Feature: | Sound Insulation | Size: | 85 Mm(3 1/4 Inch) |
---|---|---|---|
Color: | Accept Customized | Application: | Hotel,conference Room |
Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
Open Style: | Sliding | Product Name: | Folding Partition Walls |
Highlight: | sounproof folding partition,movable sound proof partitions |
Product Description
Ceiling Suspended Decorative Modern Movable Mound Proof Partition Wall With Rails
We offer
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
Product Details
BUNGE Sound Proof partition wall is made of high quality Anodized Aluminum frame with composite materials.the panel has a standard thickness of 80mm and a width up to 1219mm.Maximum height can reach 4500mm tall.its vertical seal.together with the horizontal top and bottom retractable seals providing excellent acoustic insulation property of maximum STC-48 in laboratory setting, normally used in demanding locations such as function rooms in starred hotels and convention centers.
The panels move on a ceiling track with no requirement of floor guides or rails.
The sound proof partitions may be finished with a selection from our standard un-finish MDF or un-finish
plywood board (included in the price) or with optional fabric, leather, melamine, high pressure laminate, murals, or other custom surfaces. And pass through door or glass window can be apply additionally.
We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
Easy Parking on Movable and Operable Partition System
In their stacked position, the panel form compact package and can be accommodated in the smallest of spaces depending on the room situation. The low weight of the panel and the associated structural advantages are particularly noticeable here. The four standard stack or parking track systems offer convenient operability with a minimum of noise from the individual panels as they slide into position on movable and operable partition system.We offer a range of suspension systems to suit each installation and application.
According to the project's actual size, combined with precise design of the auxiliary track, the movable partition can fold orderly, flexible and diverse collection.
Usage:
(1)Size of wall: all panels should be installed in accordance with the manufacturers recommendations.
(2)Cutting: all necessary hardware and accessories for a complete job installation are to be furnished by the contractor.
(3)Install the acoustic panels: the installation of folding partition walls panels should be carried out in a sequence from the left to the right, from upside to downside, the panels are cut to fit on site, traditional woodworking tools are suitable for cutting the panels, if panels are cut using a fine tooth table saw the panels should be cut face up to avoid scratching and at a much slower speed to avoid any tearout or chipping.
MODEL | 65 sound proof partition wall | 85 sound proof partition wall |
Panel Thickness | 65mm | 85mm |
Panel Width | 680mm-1210mm | 680mm-1230mm |
Panel Hight | 2000mm-4500mm | 3000mm-6500mm |
Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
Acoustic alreduction coefficient(db) |
32db | 45db |
Hermetic flex distance(mm) |
45mm | 45mm |
Weight(kg/m) | 17,19,20,24 | 24,25,28,38 |
Panel Material |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard,Tempered glass |
Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Advantages |
65 light-based activities are cut off cut off,their light weight,flexible operation,each door can be a single A hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can turn. |
85 screen-based activities are better off cost, weight,moderate and flexible operation,each door can be a single hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can be Tum can be pushed to move anywhere. Slide show steady and smooth transformation of space diversity. |
High degree | 2-4.5m | 3-6.5m |
The largest rail loading |
250kg/m | 450kg/m |
Usage |
Widely used in hotels,guesthouses and medium-sized exhibition, multi-functional conference hall. |
Widely used in hotels,luxury suites, function rooms,exhibition center. |
Installation methods |
slide type, curve type and folding type. |
slide type, curve type and folding type. |
MODEL | 100 movable partition wall | Ultrahigh movable partition wall |
Panel Thickness | 100mm | 120mm |
Panel Width | 680mm-1230mm | 680mm-1230mm |
Panel Hight | 5000mm-8500mm | 7000mm-17000mm |
Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
Acoustic alreduction coefficient(db) |
60db | 60db |
Hermetic flex distance(mm) |
45mm | 60mm |
Weight(kg/m) | 40,45,48,55 | 60,60,60,60 |
Panel Material |
Class-fibr board,Melamine decorative lamminate board ,Gypsum board,Color steel plate,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Advantages |
100 active partition is partition noise effect of a good,moderated 360 degrees,or both may be round hanging Tum can push the slide to any place.Slide show steady and smooth transformation of space diversiyt. |
Ultra-high partition screens employ heavy-duty steel rails and steel hanging wheels that the effective sliding can amount to 100,000 times,which is a leading technology in partition industry. |
High degree | 5-8.5m | 7-17m |
The largest rail loading |
650kg/m | 1250kg/m |
Usage |
Widely used in various types of training room,a large hotel,banquet hall. |
Widely used in airports and large exhibition hall and place. |
Installation methods | slide type, curve type and folding type. | slide type and folding type. |
Application :
*All kinds of new and old building construction of indoor and outdoor decoration
*Indoor and outdoor decoration of office buildings, hospitals, shops, restaurants, bars and other public buildings;
*Interior and exterior wall decoration of family homes, luxury apartments, villas etc; *Particularly suitable for high-rise building interior wall insulation decoration.
