Commercial Home Furniture Soundproof Partitions / Sound Proof Wall Dividers
Product Details:
Place of Origin: | Guangdong |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | Series 65 mm sound proof pertitions |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 squaremeters |
---|---|
Price: | 68/ 102dollars per square meter |
Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
Delivery Time: | Shipped in 10 days after payment, based on the quantity |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 squaremeters per month |
Detail Information |
|||
Panel Width: | 500 Mm--1220 Mm (Accept Cu | Material: | MDF+Aluminum |
---|---|---|---|
Application: | Hotel,office ,conferance Room | Color: | Color Selective (Customized) |
Thickness: | 85 Mm(3 1/4 Inch) | Finishing: | Melanimine,fabric,leather Etc. |
Feature: | Voice Insulation | STC Conffcient: | 32/50db |
Highlight: | sounproof folding partition,movable sound proof partitions |
Product Description
Commercial Space Saving Home Furniture Acoustic Sound Proof Operable Partitions
Specification:
1) Interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
2) To ensure additional friction connection, shall be integrated with magnetic strip.
3) Spring load retractable sound seal at the top and bottom element.
4) Face panel hung in acoustic free suspension, for improved sound insulation, easy redecoration of surface panels. Edges shall be protected with Aluminium profiles.
Features:
Top hung system without the need for a floor track
Retractable top and bottom seals ensure effortless movement of panels
Combines elegance with robust construction
Concealed or exposed panel edge profiles
Numerous panel stacking options for complete flexibility
Sealed for life roller assemblies provide smooth and silent movement
The system offers various levels of sound reduction
Extensive range of surface finishes available
Our services:
We ensure the Quick delivery and good quality guarantee.
Our company manufacture products according to buyer's dimension quantity, drawing or other related requirements.
After sales service including:Overseas service availabe,high quality guarantee,Free adjustment,Free training to operation and maintenance workers
Series | BG65 | BG80 / BG85 | BG100 & BG125 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
