Majestic Wall Paper Finishes Hanging Sliding Door Acoustic Operable Partition Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | BUNGE |
| Model Number: | sliding door series 85 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Square Meters |
|---|---|
| Price: | US $ 100 - 300 / Square Meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face |
| Delivery Time: | 10 working days after received your payment |
| Payment Terms: | T/T |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Frame Material: | Aluminium Frame | Surface: | Leather , Melamin , Wooden , Fabric , Wall Paper |
|---|---|---|---|
| Thickness: | ( 3.35 Inch ) ( 85mm ) | Sound Proof: | 36 / 42 DB |
| Position: | Commercial | Application: | Exhibition , Hotel , Banquet Hall .meeting Room And So On |
| Highlight: | audio diffuser panel,wood diffuser panel |
||
Product Description
Hanging Sliding Door , Majestic Wall Paper Finishes Acoustic Operable Partition Wall For Hotel Decoration
Specification for Bunge Partiiton:
Bunge movable wall partition is made of high quality anodized aluminum frame with environmentally composite materials . The panels move on a ceiling track with no requirement of floor guides or rails . The panel has a standard thickness of 65mm , 85mm and 100mm , and a width up to 1219mm.Maximum height can reach 16meters tall.
The movable partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting . Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant , schools , office , religion , hospitals , shopping arcades and many other indoor applications product.
There are wide of range face finishes are available : melamine faced MDF or Plywood , fabric carpet , fabric artificial , leather , wood veneer , high pressure laminate , Formica , acoustic panel , white board ect., panels may also be supplied unfinished for field decoration , Standard frame color is clear anodized aluminum , custom powder coating colors are available.
Bunge works with Architects designer , developers , contractors and owners in design product selection , decorative finishes , project management and after-sales warranty services as her one-stop solution business service .
Specifications:
|
Technical Parameter for Partition Panel |
Panel Width |
24~ 47 inch |
|
Panel height |
79~ 240 inch |
|
|
Sound proof |
36~42 dB |
|
|
Operation |
Manual |
|
|
Frame |
Aluminium |
|
|
Vertical profile |
Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside |
|
|
Finish options |
Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish |
|
|
Base options |
Plywood, Gypsum, steel, MDF |
|
|
Max width |
Unlimited |
|
|
Panel weight |
25-40 kg / sq |
|
|
Pass door selection |
door |
Single dor or double door |
|
Seals |
Top |
Manual |
|
bottom |
Manual |
Applications :
1. Change the room space freely dividly.
2. Heavy Track loading capacity make sure the safety of Partition .
3. Precise welding between separate rail can eliminate repairing and maintenance rate .
4. Partition retract and push easily for one people to handle the operating work .
5. Wide application: can be used in Office place , commercial place , exhibition place , Hospital place .
Bunge aluminium movable partition wall and operable partition wall acoustic movable partition for convention & exhibition centre ( used office room dividers , wood partition , movable wall , restaurant partitions , soundproof folding partition , moveable partition , wall partition , living room partition wall, sandwich panel price, accordion wall , economic partition walls , folding wall, foldable partition wall, folding partition wall , movable sound proof partition , removable wall partition , folding partition , removable partition , partition, partition wall, room divider , room dividing partition , office partition , folding partition wall panel , folding wall panel , folding wall systems )
Operation :
Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier . No floor track shall be used .
Seals :
Vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system . Retractable seal drop will be 23mm
Operation :
Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.
Track :
The tracks are made from extruded 6063 – T6 anodized aluminum . The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets . Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .
Trolley :
BUNGE Centre / Side / Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method .
Applications :
Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .
