Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room

Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 soundproof office partitions

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Soundproof Office Partitions Frame Color: Black
Surface: Melamine Application: Meeting Room Partition
Height: 3.68 M Material: Aluminum Alloy
High Light:

Folding Soundproof Office Partitions

,

Aluminum Alloy Soundproof Office Partitions

,

Melamine Soundproof Office Partitions

Product Description

Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room

Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room



Soundproof Office Partitions Stacking Options



There are three main configurations by which operable wall panels can stack to the side of the opening:



Centre Stack: Every panel hangs from a central trolley and typically hinged in pairs, perpendicular to and through the centre of a single overhead track.



Side Stack: Panels are hung from two carriers at the top end of each panel. When stacking, one carrier stays on the main track and the other in the side track.



Remote Stack: Panels have Omni-directional carriers to negotiate L or T junctions and panels are stacked entirely away from the main track.

Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room 0

Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Aluminum Alloy Folding Soundproof Office Partitions For Meeting Room 1





Soundproof Office Partitions Features



No ceiling rail on the floor


High acoustic standards: up to Rw = 55 dB


Approved in Fire Reaction Class 1 (one)


Excellent thermal insulation: heat up only spaces you use


Class of emission of formaldehyde: E1


Ecological and recyclable materials


Design: attention to detail and highly customization


Minimal storage: minimum size, only storaged in a few space


Lightness: easy to move and operate


Versatile: suitable for any premise – no need of additional works


Made-to-measure: modules can be dimensioned in height and width
