Restaurant Room Wood Temporary Sound Proof Partitions Wall For Five Star Hotel

Restaurant Room Wood Temporary Sound Proof Partitions Wall For Five Star Hotel

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 temporary soundproof partition

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Temporary Soundproof Partition Panel Thick: 100 Mm
Surface: Melamine Application: Banquet Hall Partition
Height: 3.48 M Material: MDF + Aluminum
High Light:

Wood Temporary Sound Proof Partitions

,

Restaurant Room Sound Proof Partitions

,

MDF Aluminum Sound Proof Partitions

Product Description

Restaurant Room Wood Temporary Sound Proof Partitions Wall For Five Star Hotel

Restaurant Room Wood Temporary Soundproof Partition Wall for Five Star Hotel





Temporary Soundproof Partition Detail



BUNGE temporary soundproof partition walls are made from mobile glass panels and are the ideal solution for teaching center and conference rooms and the division of waiting areas in airports and stations, entrance areas in banks, post offices and so on. The top and bottom locking and supporting edges of the door panels close along the whole width.



The structure is such that the glass need not be broken, rendering its life longer, and eventual repair work minimal. The covers for the top and bottom locking and supporting edges can be fixed using a clip. In this way surfaces are protected from both damage and scratching during assembly.


The sliding track is grooved, and with the correct screws it becomes possible to attach angle irons, for example for a false ceiling, without damaging the sliding track. The various surface finishes and wide range of colors ensure that the creativity employed will complement the architecture of the office perfectly.


The cover sheets are inter-changeable, allowing a new color scheme to be introduced at any moment. High-precision ball bearings guarantee a smooth slide and minimum sound, at a maximum weight of 150kg of the leaf. The various positioning possibilities of the panels (parallel/at 90° to the sliding track, or other) ensure that a solution is found to every requirement. The temporary soundproof partition sliding track may be straight, curved or have a polygonal shape.‎



Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Restaurant Room Wood Temporary Sound Proof Partitions Wall For Five Star Hotel 0





Temporary Soundproof Partition Features



1. Offers the greatest versatility for space division needs



2. Solves complex layout challenges



3. Satisfies high ceiling requirements with custom-engineered panels up to 60’ high



4. Accommodates wide variations in floor conditions



5. Available with easy-to-operate smart track all-steel suspension system technology, making panel storage virtually foolproof



6. Optimal for usage in conference, multi-purpose, hospitality, and convention facilities



7. Ideal for large openings and storage in remote pockets
