Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 85 mm sliding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 91 /136 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Application: Classroom,office Height: Less Than 5 M
Material: MDF Board+Aluminium Thickness: 85 Mm
Service: OEM Service Open Style: Folding
Position: Commercial Width: 800-1300 Mm
High Light:

acoustic sliding partition

,

sound proof sliding partitions

Product Description

Movable Acoustic Division Classroom Sliding Partition Walls Floor To Ceiling Thickness 85 Mm

Panel Thickness 85 mm Floor To Ceiling Movable Acoustic Division Classroom Sliding Wall Partition



Description:



The sound-proof sliding partition walls are a new way to divide spaces with elegance, while respecting the architectural environment in which they are inserted. They are composed of multiple individual elements, which flow along a horizontal guide attached to the ceiling, assembled one after another completing the entire wall.



It is not necessary any guidance on the floor, handling the elements is simple, fast and safe. The advantage of a soundproof sliding wall is essentially to occupy reduced space when it is stored, and when the wall is composed of all its elements.



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Movable Acoustic Division Classroom Sliding Partition Walls Floor To Ceiling Thickness 85 Mm 0



Advantage:



Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.


Cost savings: installation does not affect the construction of smallpox and the ground.


Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.


Easy combination: in the re-assembly can make full use of building materials.


Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.



Feature:



Top hung without track at floor level.


Retractable acoustic seals at top and base operated either by quick release handle or semi-automatically with controls.


Single or two point suspension for center or remote parking options.


Variable track arrangements for corner, three or four way abutments.



Movable Acoustic Division Classroom Sliding Partition Walls Floor To Ceiling Thickness 85 Mm 1



Sliding partition wall profile:



Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.


Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.



Our service:



Supply you excellent design proposal.


Supply you prompt and competitive price.


Supply you strict quality-compliance and punctual delivery.


Organize the shipment for you.


Reliable after service: timely service and efficient response.
