Foldable Soundproof Material Operable Partition Walls For Restaurant Economical

Foldable Soundproof Material Operable Partition Walls For Restaurant Economical

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm sliding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 98 /134 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Application: Restaurant,hotel Height: 4 M
Material: MDF Board+Aluminium Thickness: 65 Mm
Color: Multi Color Open Style: Folding
Position: Commercial Width: 500-1200 Mm
Service: OEM Service
High Light:

acoustic sliding partition

,

sound proof sliding partitions

Product Description

Foldable Soundproof Material Operable Partition Walls For Restaurant Economical

Foldable Soundproof Material Operable Wall Economical Restaurant Sliding Partitions



Description:



The sliding partition wall is a set of soundproof walls composed of every single partition. Each piece is equipped with two horizontal hanging wheels. It depends on the horizontal hanging wheel to make the hanging travel along the track. It can make a 90 degree right angle turn and travel freely.



Promote to other space collections, according to different space use needs, separated by multiple independent small space. The vertical contact points of each single piece partition are connected by concave and convex positions. The sealant strips are embedded and the upper and lower tops are equipped with a retractable soundproof seal mechanism.



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Foldable Soundproof Material Operable Partition Walls For Restaurant Economical 0



Surface treatment:



The standard colour for the track profile of the folding wall and the jamb profiles is white and the panels edge profiles are natural anodized.


There is a wide variety of panel surface treatments.



As a special solution it is possible to install a glass opening in the center of the panel. The opening can cover the whole panel, the bottom or the top.



Feature:



1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;


2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;


3. Soundproof and environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53 dB;


4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;


5.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance.



Foldable Soundproof Material Operable Partition Walls For Restaurant Economical 1



Introduction:



The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.



Movable wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kiliograms in weight, there are multiple options for Door types, parking areas and track layouts.



Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.
