Commercial Restaurant Furniture Custom Design Folding Room Dividers Movable Partition Wall
|Place of Origin:||China,Guangzhou|
|Model Number:||Series 65 mm sliding partition walls|
Payment & Shipping Terms:
|Minimum Order Quantity:||10 square meters|
|Price:||108 /123 dollar per square meter|
|Packaging Details:||Carton package, MDF batten on four section sides ,foam board on both front face.|
|Delivery Time:||Shipped in 10 days after payment, based on the quantity.|
|Payment Terms:||D/A, D/P, L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||5000 square meters per month|
|Service:||OEM Service||Height:||4 M|
|Width:||500-1200 Mm||Finished:||Acoustic Fabric, Leather|
|Material:||MDF Board+Aluminium||Thickness:||65 Mm|
|Application:||Banquet Hall, Hotel||Color:||Multi Color|
acoustic sliding partition,
sliding folding partition
Commercial Folding Room Dividers Sliding Partition Wall
Comfort, flexibility, efficiency, safety, design, and ease of use are aspects that are given top priority in the design of our movable wall systems. All movable walls are designed in such a way that the need for floor guidance has been eliminated. With manually operated spindle mechanisms and pressure sleeves the separate panels are secured firmly between floor and track. This combination ensures a stable and sound sealing wall. In regard to the lay-out of the wall, the choice of one or two point suspension offers many possibilities of parking positions, leading to a variety of solutions. Our advice and guidance during the building process with regard to dimensions and technical facilities, guarantees fast and problem free installation, which we prefer to be carried out by our experienced installation teams.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||4000 mm||6000 mm||18000 mm|
|Panel width||500-1200 mm||500-1200 mm||500-1200 mm|
|Face material||9 mm||9 mm||12 mm|
|Pass doors||Single door or Double door|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)|
1.Space management ~ Movable walls offer an effective space solution for many environments including offices, educational establishments, sporting facilities, dining and entertainment facilities, religious centres, or retail areas.
2.Smart use of space – Movable walls offer a flexible solution for making the most of an interior space. Room sizes can be changed in a matter of moments to capitalise on the revenue potential of commercial space or simply create the most efficient use of floor space.
3.Acoustics ~ the movable wall is the highest specification range of fully operable, individual-panel systems. Acoustic insulation of up to 53 dB noise reduction is achieved with a combination of acoustic infill’s and operable top and bottom seals.
4.Operation ~ space without a trace ~ when the operable seals are retracted the panels will glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide). Final closure of each panel is by a removable operating handle that extends the seal from the top and bottom of each panel forming an acoustic seal.
5.Adaptable configurations – The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
6.Panel options ~ Individual panels can be constructed with either manual or semi automatic retractable top and bottom seal. Panels are also available curved or with inset pass doors and glazed cut outs.
7.Finishes ~ our systems can be supplied in an almost endless choice, popular finishes include MFC, veneers and laminates but we can also offer dry wipe, wall coverings and fabrics.
Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.
Panels:The Panels will be made from 12mm MDF boards and shall be 100mm thick and 1230mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.
Panel Surface Finish:The panel surface will be as per the clients requirement finished either in Sliwal factory – China or by others . The normal finish such as:laminate,veneer,melamine,fabric etc.
Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23mm.
Hotel on the hanging rail activities partition products on the hotel hanging rails off the general framework of the aluminum frame material processing and production, internal partition expansion board, suitable for high-end hotel private rooms, banquet halls, conference rooms, showrooms, mufti-function Hall and so on. The sliding door base board is a MDF board or glass magnesium board. The decorative surface can be leather (cloth art) hard bag, soft bag, wallpaper, color steel veneer, hollow veneer and so on.
