3D Grooved Wooden Acoustic Ceiling Tiles / Soundproof Decorative Wall Panels
|Place of Origin:||Guangzhou,China|
|Model Number:||BG grooved wall panels|
Payment & Shipping Terms:
|Minimum Order Quantity:||No MOQ|
|Price:||US $10-28.8 per square meter.|
|Packaging Details:||Standard paper carton or customized packaging.|
|Delivery Time:||10-25 days|
|Payment Terms:||T/T, Western Union|
|Supply Ability:||50000 square meters per month.|
|Product Name:||Wooden Grooved Acoustic Panels||Feature:||Sound Insulation|
|Size:||2440 Mm*133 Mm||Finish:||Melamine|
|Back Finish:||Black Felt||Eco-friendly:||E0|
|Thickness:||12,15,18 Mm||Color:||Accept Customized|
|Type:||Acoustic Wall Panels|
grooved wood panel,
wooden sound absorption wall panel
Groove Wooden Acoustic Panels MDF Studio Auditorium Sound Absorbing Wall Panels
Groove acoustic panels are made of medium density fiberboard (MDF) material that expands depending onclimate conditions. For this reason, it is important to leave a distance, called dilatation joint,between the perimeter of the wooden panelling and walls and other fixed objects in the premise.
During summer season, panels expand considerably due to high air humidity and temperature.
A minimum dilatation joint of 8mm (1) must be guaranteed. In case of wide surfaces, this joint has to be increased. As a general rule, a minimum of 1,5mm of joint for each lineal meter of panelling is needed at each side of the room. Example: a room of 5m in width needs a minimum of 8 mm of dilatation joint at each side.
Note: minimum 15 mm with a relative air humidity > 65%.
Although the material have contact at only one side with a wall or other fixed objects, it is possible that
panelling goes off. Dilatation joints are covered with skirting boards or special profiles.
|Base material||Standard MDF, Eco-pine wood MDF, Fireproof MDF, Moistureproof MDF, Magnesium Composited MDF|
|MDF density||680kg/cubic meter~830kg/cubic meter|
|Backside finish||Fiber proof acoustic fabric|
|Fireproof grade||GB8624 2006 B,A|
|Installation||aluminum keel and clips, wood frame, gun nail|
|Backside hole diameter||10 mm|
|Veneer type thickness||0.3,0.6mm|
|Veneer texture||Mountain texture, straight line|
|Veneer tree species||
Maple,cherry,Oak, teak,walnut, Sapele,beech,birch,
|Test report||Eco protction, sound absorption, flame retardant|
Grooved acoustic panels features
1. Scientific industry : made according to acoustic theory,excellent at reducing noises,especially effective for absorbing high and middle frequency noises.
2. Artistic products : natural wood ,which may be carved according to your taste.
3. Environment-friendly : all the materials conform to the country's environmental protection standards,little wood alcohol is contained.Its natural wood is fragrant.
4. Fireproof : fireproof degree B1- the highest for wood.It has already been tested by authoritative organization.
5. Moistureproof and mildewproof : it is made of high density moistureproof and mildewproof material.
6. Easy to install : dragon bone construction is applied.
7. Industrial production : no more an extensive production,automatically controlled by computers,standardized and large scale production,improved is production capability and ensured is products quality.
Grooved acoustic panels contruction
1. Basic mterial : it is made of high density moistureproof and mildewproof board,the thickness is 9mm,12mm,15mm or 18mm.It is also acceptable to use the other board according to the customers' requirement.
2. Facing : melamine facing,color chosen according to the company's color board.
3. Sound absorption thin felt : it is black,affixed to the back of the sound absorption board,nonflammable and sound absorption.
4. Batten width : 128mm,or made according to customers' requirement.
5. Batten length : 2440mm at max.
6. Acceptable tolerance : for width it is 0.1mm,for length it is 2mm.
