Acoustic Decorative Operable Sliding Movable Partition Walls 500 - 1230 MM Width
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Model Number: | 85 mm Movable Partition Walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton packing ,MDF all around the corner |
| Delivery Time: | 30 day |
| Payment Terms: | MoneyGram, Western Union, T/T, D/P, D/A, L/C |
| Supply Ability: | 10000 square meter |
|
Detail Information |
|||
| Product Name: | Movable Partition Walls | Material: | Customized |
|---|---|---|---|
| Warranty: | 3-5 Years | Service: | ODM OEM |
| Max Height: | 6000 MM | Color: | Customized |
| Package: | Standard Wooden Case | Width: | 500 - 1230 MM |
| Based Board: | 9 Mm MDF Board | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Acoustic Decorative Operable Partition Sliding Wall Movable Partition
Product description:
| Technical Parameter for Partition Panel | Panel Width | 500~1230mm |
| Panel height | 2000~4000mm | |
| Sound proof | 32~38db | |
| Operation | Manual | |
| Frame | Aluminum | |
| Vertical profile | Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside | |
| Finish options | Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish | |
| Base options | Plywood, Gypsum, steel, MDF | |
| Max width | Unlimited | |
| Panel weight | 25-40kg/sq | |
| Pass door selection | door | Single or double door |
| Seals | Top | Manual |
| bottom | Manual |
The modern trend in buildings needs more flexibility and convenience to use the space of their rooms. Most of the building designers like to prepare open plan space, sound proof effect, and easy to operate. The solution of the designers need is the movable partition. Bunge partitions are produced in three thicknesses: 65mm, 85mm and 100mm, depending on acoustic rating (from 22db to 55db).
Operation:
When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminum overhead ceiling track system (no need for floor guide). Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configuration.
Components of Office Partition Walls:
Tracks: Made of good quality anodized aluminium 6063-T5 materials,hanging the office partition walls with wheels.
Wheels/Rollers: It is the carrier for the office partition walls ,let panels move more flexibly.Pulley bearing is more than 1600 KGS.
Connectors: Made of anodized aluminium 6063-T5 aluminum tracks,"L", "T", "+"types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation,wear-resistant.
Rock Wool: Density of 60kg/m3,help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the office partition walls.
MDF board: 9 mm thickness,density of 760kg/m3,absorbent thickness expansion rate is less than 15%.Formaldehyde emission is 34mg/100g
FAQ
1: What you should you do on site?
A beam (truss)should built on site for track installation.The minimum distance leaving for track installation from false ceiling to top ceiling is 180mm.
2: How to install?
We will provide the installation manual and video guiding the installation job.We can also dispatch the installation engineer supervising the installation as request.
3: What is lead time?
The lead time is 7 days to 10days.
4: How to transport?
Sea transport is a common mode of transportation.In an emergency,can be air freight .
5: How do the goods packing?
Carton paper package ,MDF batten cover all around cotner.
6: What is procurement procedure?
Firstly, seng us the shop drawing (if the shop drawings is not available ,you can tell us the height from false ceiling to finfshed floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation.
Thirdly, we quote the movable wall in acordance with confirmed drawings.
