Dance Studio Moving Walls Sliding Door Acoustic Operable Partitions Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | Bunge |
| Model Number: | 65 mm Movable Partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Square Meters |
|---|---|
| Price: | USD 75-95/ Square Meter |
| Packaging Details: | Carton package , Paper package |
| Delivery Time: | 10 working days after received your down payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5,000 Square Meters per Month |
|
Detail Information |
|||
| Product Name: | Movable Partition Wall | Application: | Banquet Hall ,office |
|---|---|---|---|
| Advantage: | Sliding ,folding | Material: | Wooden |
| Finish: | Melaimine | Size: | Customized |
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Dance Studio Moving Walls Sliding Door Acoustic Operable Partitions Wall
BUNGE partition wall operable
When moving a wall panel there is a 20-25 mm gap between the top pf the endersize of the head track ,there is a similanr gap between the bottom of the panel and the floor.
Once a panel is posititoned ,acoudtic integrity is maintained along the top and bottom of the panel by extending predure seals.The pressure seals are extendes and retracted by a single 180 degree ture of a removable op erating handle.
Final closure of the wall is achwared by extending a telescopic sleeve on the last panel .This action simultaneously the top and bottom seals.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door | ||
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) | ||
Key features & Benefits
- Individual panels that can be stored away for maximum space utilisation
- Operable top and bottom seals for effortless operation.
- Isolated slumunum fram construction for enhances acoustics.
- No floor track ensureing obstruction free threshold.
- There panel sizes to accommodates a wide range of accoustic requirements .
- Extensive range of surface finishes can be applied.
FAQ
1. Do you accept customization?
Yes, we can support our clients with OEM, so that it can be easier to open the local market and build a long-term partnership between us.
2. Can you offer sample?
Yes, we can offer standard samples for free, and customization is available.
3. How long is the lead time?
Normally 10-25 days upon receiving the deposit, base on the quantity 1,500 SQM.
4. Can you assist for installation?
Yes, we can arrange to assist in installation if needed.
5. How to pay ?
You can pay by western union or T/T.Cash will be ok if we do business face to face.
Product application:
The products are widely used for banquet hall ,class room ,hotel ,conference room,factory, machine room, meeting room, multi-function room, KTV, , office, car showroom and many other places.
BUNGE focuses on local strengths while eyeing the world, duo to strong innovation, reliable quality and high performance, BUNGE products are very popular among customers from home and abroad.
