Sliding Door Movable Acoustic MDF Sound Proof Partition Walls For Conference Hall
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $78-86 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sound Proof Partition Walls | Application: | Conference Hall Partitions |
|---|---|---|---|
| Color: | Color Chart, More Than 40 Colors | Open Style: | Sliding |
| Track Material: | Aluminum Alloy | Base Board: | 9 Mm MDF Board |
| High Light: | sounproof folding partition,movable soundproof partition |
||
Product Description
Sliding Door Movable Acoustic MDF Sound Proof Partition Walls for Conference Hall
Finished Project
This project was finished in January,2019. Totally 1 set of wall. Size: 9144*5886 mm, around 53.8 square meters. And the client choose 2 different finishes for this project, one is for melamine, the other is fabric finish.
On March 20th,2019, we received some nice feedback from our client who comes from Canada.
Everything goes well and his client felt satisfied and happy about our sliding folding partitions.
Client Visting
Quality is the culture of BUNGE Company.
We are always focus on the quality of sound proof partitions,and when the client come to visit our factory,all of them are satisfied on our quality.
Sound proof partition walls features
High specification ceiling track system.
Sound rating from Rw 30 to 50 dB.
Exposed protective edge or concealed profiles.
Individual plate is suspended from the top track.
Various stacking arrangements.
A telescopic seal locked between the track and the floor.
Access door is available for operable partitions.
The surface treatment may be used in hardwood veneer, vinyl, melamine, laminate or spray.
Technical information
| Model | BG65 | BG85 | BG100 | Ultra-high System |
| Suspension System | Hanging System, with ceiling rails | |||
| Basic Thickness | 65mm | 85mm | 100mm | 100 mm |
| Max Height | Max 3800 mm | Max 6000 mm | Max 8000 mm | Max 15000 mm |
| Width | 800 -1230mm | |||
| Floor/ceiling Sealing strength | Telescopic aluminum tube with rubber strip | |||
|
Side Walls Sealing Strength |
Double seal tape | |||
| Base Board Thickness | 9 mm | 9 mm | 12 mm | 12 mm |
| Vertical Profiles | Aluminum anodised with sealing profiles | |||
| Retractable Seals | Aluminum black with double rubber seals | |||
| Operation | Manual System, with supplied operating handle | |||
| Pass Doors | Single or Double Pass Through Door Available | |||
| Weight | Approx 22-35 kg/m² | Approx 25-40 kg/m² | Approx30-48 kg/m² | Approx38-68 kg/m² |
| Finish Options | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | |||
Package & Delivery
A short time of production-ONLY 5-7 DAYS
Quick and Safe Shipping
Package by Paper Carton, outside with Wooden Boxes
