Accordion Operable Sound Proof Partitions , Floor to Ceiling Movable Partition Wall System
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | 65 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcomed |
|---|---|
| Price: | US $79-98 per square meter |
| Packaging Details: | Paper carton, outside with wooden boxes |
| Delivery Time: | 12-20 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Sound Proof Partitions | Style: | Floor To Ceiling Sound Proof Partitions |
|---|---|---|---|
| Assemble: | Yes | Service: | OEM ODM Trial |
| Application: | Office Conference Room Partitions | Color: | Optional |
| High Light: | movable sound proof partitions,movable soundproof partition |
||
Product Description
Conference Room Floor to Ceiling Movable Partition Wall System Accordion Operable Sound Proof Partitions
How to install the sound proof partitions
1. After the conference room sound proof partitions rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the ceiling shape, the ground shape, whether there is a skirt line on the wall, etc., timely communicate with the on-site woodworker, and then release the line to determine the track installation. position;
2. After the horizontal line is placed, the construction side will determine the layout direction of the air-conditioning duct fire-fighting pipe, and it is convenient to determine the steel structure installation form, whether it is a straight pull or a diagonal support or a U-slot fix. These are responsible installation teams. Do the preparation before the construction, otherwise work and do things, when the impact on the site construction layout, but also to rework, seriously affect the construction progress, will also bring unnecessary trouble to Party A;
3. After the conference room sound proof partitions track is installed, the track level will be self-checked again, and finally the steel structure will be rust-proofed, and then Party A will be notified and the position of the track movable port will be clearly stated. When the ceiling is clearly indicated, it cannot be fixed with the track. Otherwise,the conference room partitions panel will likely damage the integrity of the ceiling.
Sound proof partitions technical information
| Model | BG65 Series | BG85 Series | BG100 Series | BG High-Series | |
| Suspensionsystem | Aluminum hanging | Steal Hanging | |||
| Basic Thickness | 65 mm | 85 mm | 100 mm | 100 mm | |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm | |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm | |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm | |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. | ||||
| Side walls sealing strength | Double seal tape. | ||||
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db | |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | |||
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | ||||
Sound proof partitions feature
1.Sound proof partitions can separate the space speedy and conveniently.
2.Muti-function: sound insulation,heat insulation,fireproof function.
3.Top hung system without the need for a floor track.
4.The sound proof partitions are made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.
5.Around the sound proof partitions panel, there is sound insulation rubber, it can help to insulate the sound entering.
Sound proof partitions application
Sound proof partition is a range of acoustically high-performance and decorative room divider for creating the most flexible space in offices, meeting room, schools, colleges, churches, hotel meetings, restaurants, shops, hotels, inspection centers, multi-function rooms, stations, clubs, art centers, stadiums, sports centers, art museums, the court, convention centers, golf clubs, and functional suites.
With high levels of sound attenuation and custom parking, conference room partition provides a range of solutions for even the most complex requirements.
