American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels

China American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier
American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels supplier

Large Image :  American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels

Product Details:

Place of Origin: Guangzhou, China
Brand Name: BUNGE
Certification: ISO9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $86-108 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: T/T, Western Union
Supply Ability: 20000 square meters per month
Contact Now
Detailed Product Description
Product Name: Sound Proof Partitions Finish: Melamine
Feature: Sound Proof And Movable Color: Optional
Function: Divide The Space Quickly Left And Right Telescoping:: 140 Mm

American Wooden Movable Partition System Operable Soundproof Partition Wall Panels Cost

Sound proof partitions features:


1.Sound proof partitions can separate the space speedy and conveniently.



2.Muti-function: sound insulation,heat insulation,fireproof function.



3.Top hung system without the need for a floor track.



4.The sound proof partitions are made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.



5.Around the sound proof partitions panel, there is sound insulation rubber, it can help to insulate the sound entering.

American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels


Sound proof partitions details:



Panel Configuration – The sound proof partitions panels are customized to meet specific requirements. Each sound proof partitions board thickness is 100mm and max width is 1200mm. Each sound proof partitions panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.



Overhead track system – Specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sound proof partitions for rooms through the ceiling track.The panel of sound proof partition has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.



Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.



Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the movable walls panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.





Sound proof partition walls application:



1. Studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.





2. Theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.





3. Meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.





4. Air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.

American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels



Technical data of  sound proof partition walls:

Model BG65 Series BG80 Series BG100 Series BG High-Series
Suspensionsystem Aluminum hanging Steal Hanging
Basic Thickness 65 mm 80 mm 100 mm 100 mm
Total thickness 65/75/85/95mm 80/90/100/110mm 100/120/130mm 100/120/130mm
Max Height Up to 3800 mm Up to 6000 mm Up to 8000 mm Up to 15000 mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/Ceiling Sealing Strength Telescopic aluminum tube with rubber strip.
Side walls sealing strength Double seal tape.
Sound insulation level 26-30 db 28-34 db 32-40 db 42-52 db
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

American Wooden Movable Partition System / Operable Soundproof Partition Wall Panels
