Sliding Aluminium Track Roller Flexible Sound Proof Partitions For Classroom
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sound proof wall partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 /131 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Leather,mirror And Mdf Bare Finish | Height: | Less Than 4 M |
|---|---|---|---|
| Thickness: | 65 Mm | Panel Width: | 800-1200 Mm |
| Application: | Classroom,office And Etc | Product Name: | Sound Proof Wall Partitions |
| Service: | OEM Service | Open Style: | Sliding And Folding |
| Position: | Commercial | Color: | Multi Color |
| High Light: | sounproof folding partition,movable soundproof partition |
||
Product Description
Classroom Operable Walls Sliding Aluminium Track Roller Flexible Soundproof Wall Partition
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Specification:
The soundproof wall partition is the highest specification range of fully operable, individual-panel movable partitions system. Acoustic insulation noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple in fill's and a panel assembly design that allows an acoustic break between the frame and outer layer.
The soundproof wall partition vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall. Panels are produced in three thickness, 65 mm, 85 mm and 100 mm.
Soundproof partition wall feature:
Individual panels that can be stored away for Maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Soundproof partition operation:
When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
Application:
At present, movable partition and fixed partition series products are widely used in hotels, hotels, multi-purpose halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government offices, hospitals, factories and other occasions.
Installing:
1. Before the installation of the movable partition, check the track on which the track parts are assembled on the floor in order;
2. Mark the track line and the mounting bracket at a specific location;
3. Install the movable partition rail bracket to the ceiling;
4. Check whether the movable partition is firmly fixed on the rail. When the rail and the bracket must be loosely stored in the storage area, the bracket plate can be moved to other places;
5.The appropriate position of the storage track is measured before the facility of the main track. This is very important for the placement of intersections in order to continue the installation of the following active partitions;
Structure:
The soundproof is generally composed of rails, sealing strips, horizontal wheels, reference surface materials, aluminium frames, soundproof materials, transmission rods, and sealing strips. The movable partition screen is not only used in hotels, but also in offices, homes, hotels, conference rooms, high-level clubs, golf course lounges, etc.
We can offer:
We offer quality, reliable solutions with partitions and moveable walls (solid or glass) and accordion doors, security grilles, and wood roll-up doors and shutters. We provide pricing, technical assistance, installation and design options for General Contractors, Architects, and Interior Designers.
