Acoustic Sound Proof Partitions , Easy Installation Removable Partition Walls
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ASTM E90 |
| Model Number: | 65 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity available |
|---|---|
| Price: | US $75-108 per square meter. |
| Packaging Details: | Paper Carton, outside with wooden boxes. |
| Delivery Time: | 15-25 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 8000 square meters per month. |
|
Detail Information |
|||
| Product Name: | Sound Proof Partitions | Partition Material: | MDF + Melamine |
|---|---|---|---|
| Sample: | Free | Contract Range: | 22.5 Mm |
| Sound Insulation Coefficient: | 30-55 Db | Finishing: | Melamine, Fabric, PU Leather Etc |
| High Light: | sounproof folding partition,movable soundproof partition |
||
Product Description
Easy Installation Removable Partition Walls Acoustic Sound Proof Partitions
Sound proof partition details
Increasingly, flexible and efficient space utilisation is becoming a must for offices, hotels, exhibition centres, studios and similar. With our movable sound proof partition walls system, you can have more choice to arrange your space rather than a room. Is not only provide visual insulation but also sound insulation which give you a more private space, the sound insulation could be 35dB to 55dB, as well as a concreat wall.
Sound proof partition is made of high quality anodized aluminum frame with environmentally composite materials.the panels move on a ceiling track with no requirement of floor guides or rails which provide you a better environment.
Sound proof partitions features
- Top hung system without floor track;
- Sound insulation coefficient STC 26 to 55db based on the material choose;
- Thickness panel:65mm,85mm,100mm,110mm,125mm, height from 2meters to18meters;
- More choices for surface finishes are available.
- such as Wood Veneer,Melamine.Leather,Fabric,Glass.
Sliding partition walls technical information
| Model | 65 Sliding Partition Wall |
85 Sliding Partition Wall |
100 Sliding Partition Wall |
Ultrahigh Sliding Partition Wall |
| Panel Thickness | 65 MM | 85 MM | 100mm | 100mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm | 680mm-1230mm | 680mm-1230mm |
| Panel Height | 2000mm-4500mm | 3000mm-6500mm | 5000mm-8500mm | 7000mm-17000mm |
| Frame | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
32db | 45db | 60db | 60db |
|
Hermetic flex distance(mm) |
45mm | 45mm | 45mm | 60mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 | 40,45,48,55 | 60,60,60,60 |
| Faceplate Material |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
| Panel Surface Finish |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Sound proof partitions FAQ
Q1. Can I have a sample order for sound proof partition?
A: The size of sound proof partition is so big, we can give you a free small sample to test our quality.
Q2. What about the lead time?
A:Sample needs 7-12 days, mass production time needs 15 - 20 days for order quantity more than
Q3. Do you have any MOQ limit for sound proof partition order?
A: NO MOQ, small quantity available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by sea. It usually takes 2-5 weeks to arrive.
Q5. How to proceed an order for sound proof partition?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the drawing and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the sound proof partitions?
A: Yes, we offer 5 - 10 years warranty to our products.
