Aluminum Acoustic Movable Partition Walls / Function Room Sliding Folding Partition
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ASTM E90 |
| Model Number: | 65 mm movable partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | US $78-105 per square meter. |
| Packaging Details: | Paper carton,outside with wooden boxes. |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Feature: | Acoustic,sound Proofing | Thickness: | 65 Mm |
|---|---|---|---|
| Size: | Accept Customized | Colors: | Can Be Customized |
| Width: | 800-1220 Mm | Height: | 20000-16000 Mm |
| Product Name: | Movable Partition Walls | Sample: | Free |
| Application: | Hotel Banquet Hall,conference Room | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Function Room Sliding Folding Partition Aluminum Acoustic Movable Partition Walls
Movable partition walls details
The movable partition walls consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.
Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance.
There are wide of range face finishes are available :melamine faced MDF or plywood, fabric, carpet, fabric, artificial, leather,wood veneer, high pressure laminate,Formica ,acoustic panel,white boad ect., Panels can also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.
Increasingly, flexible and efficient space utilisation is becoming a must for offices, hotels, exhibition centres, studios and similar. With our movable partition walls system, you can have more choice to arrange your space rather than a room. Is not only provide visual insulation but also sound insulation which give you a more private space, the sound insulation could be 35dB to 55dB, as well as a concreat wall.
Movable partition wall is made of high quality anodized aluminum frame with environmentally composite materials.The sliding partition walls panels move on a ceiling track with no requirement of floor guides or rails which provide you a better environment.
Features & Benefits
1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.
2-Top supported without floor track or guide, only have track on the ceiling.
3- clear anodized extruded aluminum tracks and frames,customized powder coated color are available.
4- Sound insulation certificate :STC 32db to 52db, ASTM standard of acoustic tested in HongKong.
5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.
6- Fast delivery and Rich experiences in oversea project installation guide & supervision.
Movable partition walls technical informations
| MODEL | 65 movable partition wall | 85 movable partition wall |
| Panel Thickness | 65 mm | 85 mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm |
| Panel Hight | 2000mm-4500mm | 3000mm-6500mm |
| Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
32db | 45db |
|
Hermetic flex distance(mm) |
45mm | 45mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 |
| Panel Material |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard,Tempered glass |
| Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
| Advantages |
65 light-based activities are cut off cut off,their light weight,flexible operation,each door can be a single A hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can turn. |
85 screen-based activities are better off cost, weight,moderate and flexible operation,each door can be a single hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can be Tum can be pushed to move anywhere. Slide show steady and smooth transformation of space diversity. |
| High degree | 2-4.5m | 3-6.5m |
|
The largest rail loading |
250kg/m | 450kg/m |
| Usage |
Widely used in hotels,guesthouses and medium-sized exhibition, multi-functional conference hall. |
Widely used in hotels,luxury suites, function rooms,exhibition center. |
| Installation methods |
slide type, curve type and folding type. |
slide type, curve type and folding type. |
| MODEL | 100 movable partition wall | Ultrahigh movable partition wall |
| Panel Thickness | 100 mm | 100 mm |
| Panel Width | 680mm-1230mm | 680mm-1230mm |
| Panel Hight | 5000mm-8500mm | 7000mm-17000mm |
| Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
60db | 60db |
|
Hermetic flex distance(mm) |
45mm | 60mm |
| Weight(kg/m) | 40,45,48,55 | 60,60,60,60 |
| Panel Material |
Class-fibr board,Melamine decorative lamminate board ,Gypsum board,Color steel plate,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
|
Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
| Advantages |
100 active partition is partition noise effect of a good,moderated 360 degrees,or both may be round hanging Tum can push the slide to any place.Slide show steady and smooth transformation of space diversiyt. |
Ultra-high partition screens employ heavy-duty steel rails and steel hanging wheels that the effective sliding can amount to 100,000 times,which is a leading technology in partition industry. |
| High degree | 5-8.5m | 7-17m |
|
The largest rail loading |
650kg/m | 1250kg/m |
| Usage |
Widely used in various types of training room,a large hotel,banquet hall. |
Widely used in airports and large exhibition hall and place. |
| Installation methods | slide type, curve type and folding type. | slide type and folding type. |
